Welch MP 601 E - Device Data

Technical Data
12 412721
4.3 Device Data
Parameter
Unit
Diaphragm pump types
MP 601 E
(single-stage)
MPC 601 E
(single-stage)
MP 301 Z
(two-stage)
MPC 301 Z
(two-stage)
Pumping speed 50/60 Hz
DIN 28432
at speed of 1500 rpm
m
3
/ h
3.8 / 4.2
2.3 / 2.5
l / min
63 / 70
38 / 42
Ultimate pressure
at speed of 1500 rpm
mbar
75
8
Ultimate pressure
with gas ballast
(with MPC only) at speed of 1500 rpm
-
90
-
18
Max. inlet pressure
bar
1
Max. outlet pressure
1
Intake port
-
Small flange DN 16 KF
optional
Hose nozzle DN 8 for hose inside diameter 8 mm
Exhaust port
Hose nozzle DN 8 for hose inside diameter 8 mm
Ambient temperature
°C
+ 10 to + 40
Max. operating gas temperature
+ 60
Bearing
-
maintenance-free
Reference surface sound
pressure level
DIN EN ISO 2151
dB (A)
44
Voltage
V
230; 115; 230/400
(generally with motor protection switch, switch and cable)
Frequency
Hz
50 / 60
Power
W
180
Operating mode
-
S 1
Type of protection
DIN EN 60529
IP 54
Motor / Class of insulation
DIN EN 600034-1
F (160°C)
Type Examination Certificate no.
(at MPC only)
-
WELCH_ATEX_03-01
Designation EX (at MPC only)
II3G IIC T3 X (internal Atm. only)
Weight
kg
11.2
Dimensions (W/D/H)
mm
230 / 265 / 170
Order numbers for :
-
- Diaphragm pump (230V)
inclusive mains connection cables
with plug CEE, UK
411721
412721
411722
412722
- Diaphragm pump - X2 (230V)
inclusive mains connection cables
with plug CEE, UK
-
412721-03
-
412722-17
- Diaphragm pump (115V)
inclusive mains connection cable
with plug US
411721-01
412721-01
411722-01
412722-01
- Diaphragm pump (230/400V)
inclusive mains connection cable
with plug CEE
411721-02
412721-02
411722-02
412722-02
- Diaphragm pump - X2 (230/400V)
inclusive mains connection cable
with plug CEE
-
412721-04
-
-
The information presented in this material is based on technical data and test results of nominal units. It is believed
to be accurate and reliable and is offered as and aid to help in the selection of products.
It is the responsibility of the user to determine the suitability of the product for the intended use and the user as-
sumes all risk and liability whatsoever in connection therewith. Gardner Denver Thomas GmbH does not warrant,
guarantee or assume any obligation or liability in connection with this information.
