Weldmatic 215Operators Manual
Model No. CP111-0, Iss A 02/05 17
Quality, Reliability, Performance
Item # Part # Description Qty
1 CP42-24/6 Wheel, Rubber, Castor 2
2 PAN001 Base 1
3 CP42-0/3 Wheel, Rubber, Fixed 2
4 MC11-53/6 Ratchet Cap 1
5 PAN006 Side Panel, Lower 1
6 PAN003 Front Panel 1
7 W29-1/20 Slam Action Catch 2
8 M0010 Control Knob, Small 1
9 MC100-54 Control Knob, Large 1
10 PAN007 Door 1
11 W41-0/1 Hinge Set Left Hand 1
12 PAN008 Side Wrap 1
13 W41-0/2 Hinge Set Right Hand 1
14 MZ200923 Plastic Moulding, Gun Holder / Cable Hanger 1
15 MZ208164 Plastic Moulding, Front Panel 1
16 E0027 Switch, Coarse, Off/1/2/3 1
17 W39-0/1 Switch, Fine, 1/2/3 1
18 SA140-0/2 Socket, Dinse 2
19 WGEC3 Plug, Dinse 1
20 WF007 Euro adapter 1
21 AM177 Spool holder assembly 1
22 AM133-3 R clip 1
23 Wirefeed Assembly (see page 18)
24 PAN010 Circuit Board Cover 1
25 CP109-12N Wirefeed Control Pcb 1
26 PAN009 Cylinder Bracket 1
27 PAN005 Shelf Panel 1
28 PAN002 Back Panel 1
29 CP106-0/3 Mains Lead and Plug 1
30 CP107-0/2 Fan Assembly 1
31 TFM001N Welding Transformer Assembly, Wired 1
Not shown CP104-16/2 Thermostat (included in transformer) 1
32 IND003 Inductance Assembly 1
33 CP101-0/18 Gas valve 24 vdc 1
34 CP3-9/8 Thermostat (included in rectifier) 1
35 CP102-51/2 SCR Module 1
36 CP106-0/1 Rectifier 1
To Next Page
