CMP203 User Guide
75
120~1080, Framerate：24~60,
Scan Type：Progressive）
Video Aspect Ratio
Automatic , 16×9（SD）, 4×3（SD）
Provider Name
Length is 0~31
Profile
MAIN
HIGH
Click Service Info in the line of Audio Encoding to set audio encoding.
Audio Encoder Details
Range
Audio Encoder Details
Range
Audio Enable
Enable/Disable
Delay(ms)
-2000~2000
Audio Type
MPEG1_Layer2
AAC
AC3
Audio Bitrate(Kbps)
32~192(MPEG1_Lay
er2) 32~192(AAC)
96~192 (AC3)
Volume(dB)
-20~20
Audio PID
32~8190
Shelter Parameters
Range
Shelter Parameters
Range
Shelter
Enable/Disable
X
0~1920 (Dual)
Y
0~1080 (Dual)
Width
2~1920 (Dual)
Height
2~1080 (Dual)
Color
White/Black/Blue/Green/Red
CE2-HDMI-05A >Output
