INTRODUCTION
Thanks for purchasing a WEN Lathe. We know you are excited to put your tool to work, but first, please take a mo-
ment to read through the manual. Safe operation of this tool requires that you read and understand this operator’s
manual and all the labels affixed to the tool. This manual provides information regarding potential safety concerns,
as well as helpful assembly and operating instructions for your tool.
NOTE: The following safety information is not meant to cover all possible conditions and situations that may occur.
WEN reserves the right to change this product and specifications at any time without prior notice.
At WEN, we are continuously improving our products. If you find that your tool does not exactly match this manual,
please visit wenproducts.com for the most up-to-date manual or contact our customer service at 1-800-232-1195.
Keep this manual available to all users during the entire life of the tool and review it frequently to maximize
safety for both yourself and others.
SAFETY ALERT SYMBOL: Indicates danger, warning, or caution. The safety symbols and the explanations
with them deserve your careful attention and understanding. Always follow the safety precautions to reduce the
risk of fire, electric shock or personal injury. However, please note that these instructions and warnings are not
substitutes for proper accident prevention measures.
SPECIFICATIONS
Model Number 34034
Motor 120V, 60 Hz, 6A
Swing Over Bed 14 inches (355mm)
Distance Between Centers 20 inches (510 mm)
Center Height 7 inches (178mm)
Spindle Speeds 250-720, 600-1700, 1200-3550 RPM
Spindle Taper MT2
Spindle Thread 1 inch x 8 TPI
Tailstock Taper MT2
Quill Travel 3-1/2 inches
Tool Rest Length 8 inches
Face Plate Diameter 4 inches (102mm)
Weight 125.7 lbs
Product Dimensions 38 x 11.8 x 22.6 inches
