Wen 36725

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 36725-001 Right Handle 1
2 36725-002 Line Pressing Board 1
3 36725-003 Screw ST4x16 9
4 36725-004 Switch 1
6 36725-006 Power Cord Sheath 1
7 36725-007 Left Handle 1
8 36725-008 Screw ST4X25 4
9 36725-009 Housing Cover 1
10 36725-010
Carbon Brush
Protector
2
11 36725-011 Housing 1
12 36725-012 Stator Assembly 1
13 36725-013 Screw ST4x65 2
14 36725-014 Fan Shroud 1
15 36725-015 Bearing 608 1
16 36725-016 Brush Holder 2
17 36725-017
Carbon Brush 2
18 36725-018
19 36725-019 Rotor Assembly 1
20 36725-020 Bearing 6000 1
21 36725-021 Rubber Column 1
22 36725-022
Depth Locking
Screw
1
23 36725-023 Left Aluminum Head 1
24 36725-024 Retaining Washer 1
25 36725-025 Screw M6x14 1
26 36725-026 Screw M6x16 1
27 36725-027 Oil Bearing 1
28 36725-028
Dust Port Adapter
1.5” O.D.
1
29 36725-029 Gear 1
30 36725-030 Main Shaft 1
No. Part No. Description Qty.
31 36725-031 Elastic Cylindrical Pin 1
32 36725-032 Retaining Ring 1
33 36725-033 Bearing 6001 1
34 36725-034 Bearing Base 1
35 36725-035 Screw M4x12 4
36 36725-036 Spring 1
37 36725-037 Screw ST4x10 1
38 36725-038
Lower Blade Guard
Lever
1
39 36725-039 Protection Guard Knob 1
40 36725-040 Coil Spring 1
41 36725-041 Inner Flange 1
42 36725B Blade 1
43 36725-043 Outer Flange 1
44 36725-044 Washer 1
45 36725-045 Screw M8x14 1
46 36725-046 Right Aluminum Head 1
47 36725-047 Screw M5x12 3
48 36725-048 Rivet Screw 2
49 36725-049 Base Washer 2
50 36725-050 Depth Guide Bracket 1
51 36725-051 Rip Guide Lock Knob 1
52 36725-052 Base 1
53 36725-053 Bevel Locking Knob 1
54 36725-054 Retaining Ring 1
55 36725-055 Screw 5.5xM5x12 1
56 36725-056 Angle Brackets 1
57 36725-057 Connecting Pin 1
58 36725-058 Spindle Lock Spring 1
59 36725-059 Spindle Lock 1
60 36725-060 Parallel Guide 1
61 36725-061 Hex Wrench M6 1
