Wen 3922

EXPLODED VIEW & PARTS LIST
No. Model No. Description Qty.
1 3920B-001 Screw M5x8 2
2 3922-002 Screw M4x20 1
3 3922-003 Side Panel 1
4 3920B-004 Nut M6 5
5 3920B-005 Spring Washer M6 4
6 3920B-006 Base 1
7 3920B-007 Oil Cap 4
8a 3920C-008A Left Arm Housing 1
8b 3920C-008B Right Arm Housing 1
9 3920B-009 Tension Bolt Assembly 1
10 3920B-010 Extension Spring 1
11 3920B-011 Pressure Plate 2
12 3920B-012 Spring Washer M4 1
13 3920B-013 Screw M4X10 2
14 3920C-013 Lower Arm 1
15 3920C-014 Upper Arm 1
16 3920C-015 Arm Bearing 4
17 3920C-016 Blast Pipe 1
18 3920B-018 Screw M5x6 1
19 3922-019 Side Panel Lock Knob 1
20 3920B-020 Spring Washer M5 1
21 3920B-021 Screw M5x35 5
22 3920B-022 Screw M4x6 2
23 3920B-023 Bellows Cap 1
24 3920B-024 Screw M5x28 1
25 3920B-025 Table Lock Knob 1
26 3920B-026 Switch Fixing Board 1
27 3920B-027 Switch 1
28 3920B-028 Bellows 1
29 3920B-029 Fixing Plate 2
30 3920B-030 Bolt M6x20 4
31 3920B-031 Blade Holder 2
32 3920B-032 Washer M4 4
33 3922-033 Thumb Screw 2
34 3920B-034 Clamping Board 2
35 3920B-076 Blade 15TPI 1
36 3920B-036 Screw M5x25 1
37 3920B-037 Big Cushion 1
No. Model No. Description Qty.
38 3920B-038 Eccentricity Connector 1
39 3920B-039 Bearing 625Z (80025) 2
40 3920B-040 Nut M5 1
41 3920B-041 Clamping Board 1
42 3920B-042 Screw ST4.2x9.5 5
43 3920B-043 Washer 1
44 3920B-044 Screw M5x16 1
45 3922-045
Back Side Panel Lock
Knob
1
46 3920B-046 Drop Foot Lock Knob 1
47 3920B-047 Drop Foot Fixing Pole 1
48 3920B-048 Screw M5x30 2
49 3920B-049 PCB 1
50 3920B-050 Drop Foot 1
51 3920B-076-1 Blade 18TPI Pinned 1
52 3920B-052 Screw M6x10 1
53 3920B-053 PVC Pipe 1
54 3920B-054 Big Washer M6 1
55 3920B-055 Screw M6x40 1
56 3920B-056 Bolt M6x16 4
57 3920B-057 Washer M6 1
58 3920B-058 Spring 1
59 3920B-059 Screw M6x25 1
60 3920B-060 Work Table Bracket 1
61 3920B-061 Pointer 1
62 3920B-062 Bevel Scale 1
63 3920B-063 Work Table 1
64 3920B-064 Work Table Insert 1
65 3920B-065 Speed Adjusting Knob 1
66 3920B-066 Screw M5x6 1
67 3920B-067 Power Cord 1
68 3920B-068 Screw M4x8 2
69 3920B-069 Screw M8x12 1
70 3920B-070 Eccentric Wheel 1
71 3920B-071 Motor 1
72 3920B-072 Switch Box 1
73 3920B-073 Cord Clamp 1
74 3920B-074 Screw M4X12 4
21
