Wen 3959 Manual

EXPLODED VIEW AND PARTS LIST
No. Part No. Description Qty.
1 3959-001 Lower Door 1
2 3959-002 Hex Screw M6X10 2
3 3959-003 Spring Washer Φ6 3
4 3959-004 Nut M6 5
5 3959-005 Screw M4X10 4
6 3959-006 Window 1
7 3959-007 Upper Door 1
8 3959-008 Saw Blade 1
9 3959-009 Shaft Circlip 2
10 3959-010 Bearing 4
11 3959-011 Hole Circlip Φ26 4
12 3959-012 Screw M4X8 2
13 3959-013 Rubber Gasket 2
14 3959-014 Driven Pulley 1
15 3959-015 M8X70 Bolt 1
16 3959-016 Brush 1
17 3959-017 Scale Label 1
18 3959-018 Upper Wheel Shaft 1
19 3959-019 Upper Wheel Shaft Base 1
20 3959-020 Split Washer M6 2
21 3959-021 Connection Shaft 1
22 3959-022 Blade Wheel 2
23 3959-023 U Type Support 1
24 3959-024 Bolt 1
25 3959-025 Hex Nut M4 2
26 3959-026 Switch 1
27 3959-027 Switch Plate 1
28 3959-028 Locking Washer 1
29 3959-029 Guide Base 1
30 3959-030 Screw 7
31 3959-031 Guide Cover 1
32 3959-032 Cover Spring 1
33 3959-033 Screw 1
34 3959-034 Slide Board 1
No. Part No. Description Qty.
35 3959-035 Upper Guide Slide Bar 1
36 3959-036 Hex Screw M4X4 1
37 3959-037 Pin 5X14 4
38 3959-038
Upper Blade Guide Sup-
port
1
39 3959-039 Upper Support Shaft 1
40 3959-040 Flat Washer M5 3
41 3959-041 Ball Bearing 2
42 3959-042 Bearing Fastening Screw 2
43 3959-043 Hex Screw M5X10 3
44 3959-044 Hex Screw M5X12 4
45 3959-045
Philips Screw+Flat
Washer+Spring Washer As-
sembly M4X8
6
46 3959-046 Belt 1
47 3959-047 Hex Nut M12X1.5 1
48 3959-048 Spring Washer M12 1
49 3959-049 Lower Wheel Shaft 1
50 3959-050 Hex Screw M5X10 1
51 3959-051 Big Flat Washer 1
52 3959-052 Driven Pulley 1
53 3959-053 Guide Plate 1
54 3959-054 Hex Nut M10 1
55 3959-055 Hex Screw M6X8 2
56 3959-056 Blade Lower Guard 1
57 3959-057 Saw Body 1
58 3959-058 Block 1
59 3959-059 Tension Spring 1
60 3959-060 Tension Handle 1
61 3959-061 Flat Washer D8 2
62 3959-062 Hex Nut M8 1
63 3959-063 Wing Locking Nut 1
64 3959-064
Blade Wheel Adjusting
Knob
1
65 3959-065 6P4 Clip 2
16

Wen 3959 Specifications

General

Brand	Wen
Model	3959
Category	Saw
Language	English
