Wen 3962T User Manual

EXPLODED VIEW & PARTS LIST
23
No. Part No. Description Qty.
63 3962-063
Upper Guide
Adjusting Knob
1
64 3962-064 Spring 1
65 3962-065 Lock Knob 1
66 3962-066 Lower Guard 1
67 3962-067
M6-1.0x10mm
Socket Head Bolt
2
68 3962-068 Shaft 1
69 3962-069 M6-1.0mm Hex Nut 4
70 3962-070
M6-1.0x20mm Hex
Head Bolt
4
71 3962-071
4.8-1.6x13mm
Thread Forming
Screw
2
72 3962-072 Limiting Plate 1
73 3962-073 Upper Blade Guard 1
74 3962-074 Rack 1
75 3962-075 Sliding Cover 1
76 3962-076
M5-0.8x6mm Socket
Head Bolt
1
77 3962-077 Connecting Shaft 1
78 3962-078 Support Block 1
79 3962-079
M6-1.0x8mm Set
Screw
1
80 3962-080
4.8-1.6x13mm
Thread Forming
Screw
1
81 3962-081 Knob 1
82 3962-082 5mm Flat Washer 1
83 3962-083 Bearing Cover 1
84 3962-084 Shaft 1
85 3962-085 607ZZ Ball Bearing 1
86 3962-086 Knob 1
87 3962-087
M5-0.8x16mm
Socket Head Bolt
2
88 3962-088 5mm Flat Washer 2
89 3962-089 Shaft 2
90 3962-090 607ZZ Ball Bearing 2
No. Part No. Description Qty.
91 3962-091 M6-1.0mm Hex Nut 1
92 3962-092 626ZZ Ball Bearing 1
93 3962-093
M6-1.0x16mm
Socket Head Bolt
1
94 3962-094
M6-1.0mm Square
Nut
2
95 3962-095 Lower Guide Plate 1
96 3962-096 Bushing 2
97 3962-097 626ZZ Ball Bearing 2
98 3962-098
6-1.0x20mm Socket
Head Bolt
2
99 3962-099
6-1.0x10mm Socket
Head Bolt
1
100 3962-100 6mm Flat Washer 1
101 3962-101 6-1.0mm Hex Nut 2
102 3962-102
M6-1.0x20mm
Socket Head Bolt
2
103 3962-103
M6-1.0x8mm Set
Screw
1
104 3962-104 Motor Pulley 1
105 3962-105 Belt 1
106 3962-106
M6-1.0x16mm Hex
Head Bolt
4
107 3962-107 Motor Support Plate 1
108 3962-108 8mm Flat Washer 2
109 3962-109
M8-1.25x20mm
Socket Head Bolt
2
110 3962-110 5x5x25mm Key 1
111 3962-111 Motor 1
112 3962-112
M4.2-1.4x13mm
Thread Forming
Screw
3
113 3962-113 Dust Port 1
114 3962-114 Dust Port Cover 1
115 3962-115 3x22mm Pin 1
116 3962-116 Power Cord 1
117 3962-117 Guide Rail Lock Knob 4
118 3962-118 Table Insert 1
