5. If you must replace a wheel be sure to obtain one with a safe rated speed at least as high as the “NO LOAD”
RPM marked on your grinder’s nameplate. Replacement wheels must have a 6 inch diameter, a matching arbor
size and should be a maximum of 3/4 inch wide. Always check new wheels for cracks. Be sure the tool is un-
plugged before attempting repairs and maintenance.
CAUTION: Never use caustic agents to clean the plastic parts of the tool. Water must never come into contact
with the grinder. The use of any other accessories is not recommended and may result in serious injury.
POWER CORD REPLACEMENT
If replacement of the power supply cord is necessary, this must be done by an authorized service center in order
to avoid a safety hazard.
STORAGE
Store the bench grinder and the grinding wheels to prevent them from the potential hazards of moisture, contain-
ments, and other damage.
MAINTENANCE
EXPLODED VIEW AND PARTS LIST
No. Part No. Description
26 4276-026 Switch
27 4276-027 Switch Plate
28 4276-028 Fastener Assembly
29 4276-029 Bottom Plate
30 4276-030 Fastener Assembly
31 4276-031 Rubber Foot
32 4276-032 Capacitor
33 4276-033 Flat Washer
34 4276-034 Hex Nut
35 4276-035 Right Guard Cover
36 4276-036 Grinding Wheel
37 4276-037 Right Guard
38 4276-038 Right Tool Rest
39 4276-039 Fastener Assembly
40 4276-040 Bearing
41 4276-041 Cord Clip
42 4276-042 Rotor
43 4276-043 Right Eyeshield
44 4276-044 Right Eyeshield Bracket
45 4276-045 Power Cord
46 4276-046 Base
47 4276-047 Lamp
48 4276-048 Eyeshield Knob
49 4276-049 Locking Knob
No. Part No. Description
1 4276-001 Bolt
2 4276-002 Spring Washer
3 4276-003 Flat Washer
4 4276-004 Left Eyeshield Bracket
5 4276-005 Left Eyeshield
6 4276-006 Tool Rest Lock Knob
7 4276-007 Left Tool Rest
8 4276-008 Nut
9 4276-009 Left Guard
10 4276-010 Carriage Bolt
11 4276-011 Fastener Assembly
12 4276-012 Spark Deflector
13 4276-013 Fastener Assembly
14 4276-014 Flange
15 4276-015 Grinding Wheel
16 4276-016 Hex Nut
17 4276-017 Left Guard Cover
18 4276-018 Screw
19 4276-019 Hex Nut
20 4276-020 End Cap
21 4276-021 Washer
22 4276-022 Stator
23 4276-023 Cord Brushing
24 4276-024 Washer
25 4276-025 Fastener Assembly
12
