KNOW YOUR BENCH GRINDER
1
2
3
4
5
6
7
8
9
10
11
1. INNER WHEEL GUARD - Covers the grinding
wheels and protects against accidental contact
2. TOOL RESTS-Used to support the workpiece. Ad-
justable to provide angled surfaces.
3. 36-GRIT GRINDING WHEEL - Used to remove
heavy material from the workpiece
4. EYESHIELD - Protective see-through shields to pre-
vent any loose debris from contacting the operator
5. LOCKING KNOB - Lock the eyeshield in position
6. FLEXIBLE WORK LIGHT - Provides light to the
operator during grinding operations
7. SPARK DEFLECTOR - Prevents hot sparks and
debris from contacting the operator
8. WHEEL COVER - Covers the grinding wheels and
provides quick access for routine maintenance
9. 60-GRIT GRINDING WHEEL - Used to remove
light material from the workpiece
10. ON/OFF SWITCH - Used to turn ON and turn
OFF the bench grinder
11. MOTOR HOUSING - Contains the electrical
motor
