Wen 4280 User Manual

No. Part Number Description Qty.
1 4280-001 Coolant Tray 1
2 4280-002 Circuit Board 1
3 4280-003 Screw (ST2.9x5) 2
4 4280-004 Circuit Board Cover 1
5 4280-005 Screw Assembly (M4X8) 3
6 4280-006 Capacitor 1
7 4280-007 Base 1
8 4280-008 Cord Plate 1
9 4280-009 Screw (M5x8) 2
10 4280-010 Cord Clip 1
11 4280-011 Power Cord 1
12 4280-012 Washer (D12) 1
13 4280-013 Light Subassembly 1
14 4280-014 Screw (M5x8) 2
15 4280-015 Screw (M5X48) 4
16 4280-016 Left Wheel Guard Cover 1
17 4280-017 Left Hex Nut (M16) 1
18 4280-018 Flange 4
19 4280-019 Left Grinding Wheel (#36) 1
20 4280-020 Screw Assembly (M5X10) 6
21 4280-021 Left Wheel Guard 1
22 4280-022 Bolt (M6x12) 2
23 4280-023 Left Shield Bracket 1
24 4280-024 Screw Assembly (M5X10) 4
25 4280-025 Nut (M4) 5
26 4280-026 Eye Shield 2
27 4280-027 Screw (M4X12) 4
28 4280-028 Eyeshield pressure plate 2
29 4280-029 Washer (D6) 2
30 4280-030 Locking Nut (M6) 2
31 4280-031 Locking Knob ( M6X17) 2
32 4280-032 Left Work Rest 1
33 4280-033 Washer (D5) 2
34 4280-034 Spring Washer (D5) 2
35 4280-035 Left Work Rest Bracket 1
36 4280-036 Right Shield Bracket 1
37 4280-037 Right End Bell 1
38 4280-038 Hex Bolt (M5x6) 1
39 4280-039 Bushing 1
40 4280-040 Screw (M2.5X6) 2
No. Part Number Description Qty.
41 4280-041 Sensor 1
42 4280-042 Bushing 3
43 4280-043 Nut (M5) 4
44 4280-044 Left Eye Shield Bracket 2
45 4280-045 Cover 1
46 4280-046 Bearing (6204) 2
47 4280-047 Square Neck Bolt (M5X51) 2
48 4280-048 Rotor 1
49 4280-049 Stator 1
50 4280-050 Spring Lock Washer 1
51 4280-051 Left End Bell 1
52 4280-052 Screw Assembly (M5X160) 4
53 4280-053 Nut (M5) 4
54 4280-054 Locking Washer (D4) 2
55 4280-055 Screw (M4x16) 1
56 4280-056 Knob ((3/16)’) 1
57 4280-057 Hex Bolt Assembly (M8x22) 2
58 4280-058 Potentiometer 1
59 4280-059 Switch Plate 1
60 4280-060 Switch 1
61 4280-061 Washer 1
62 4280-062 Speed Adjustment Knob 1
63 4280-063 Screw Assembly (M5X16) 4
64 4280-064 Screw Assembly (M4X6) 4
65 4280-065 Base Plate 1
66 4280-066 Rubber Feet 4
67 4280-067 Right White Grinding Wheel (#80) 1
68 4280-068 Hex Nut (M16) 1
69 4280-069 Right Wheel Guard Cover 1
70 4280-070 Right Work Rest 1
71 4280-071 Hex Nut (M5) 4
72 4280-072 Right Work Rest Bracket 1
73 4280-073 Right Wheel Guard 1
74 4280-074 Angled Right Work Rest 1
75 4280-075 Screw (M4X8) 2
76 4280-076 Wheel Dresser Mount 1
77 4280-077 Wheel Dresser 1
78 4280-078 Locking Nut (M5) 2
79 4280-079 Hex Nut (M12) 1
EXPLODED VIEW & PARTS LIST
16
