EXPLODED VIEW & PARTS LISTEXPLODED VIEW & PARTS LIST
17
No. Part No. Description Qty.
1 49140-001 Gearbox 1
1-1 49140-001.1 Gearbox Cover 1
1-2 49140-001.2 Output Shaft 1
1-3 49140-001.3 Washer, 10.5×6.5 1
1-4 49140-001.4 Shaft Bushing 1
1-5 49140-001.5 Spring 1
1-6 49140-001.6 Clutch Ring 1
1-7 49140-001.7 Clutch 1
1-8 49140-001.8 Clutch Pins 6
1-9 49140-001.9 Clutch Base 1
1-10 49140-001.10 Ring Gear 1
1-11 49140-001.11
Secondary Planetary
Gearset
1
1-12 49140-001.12
Planetary Gear
Carrier
1
1-13 49140-001.13
Primary Planetary
Gearset
1
1-14 49140-001.14 End Washer, 31.7×10 1
2 49140-002 Screw, M2.5×8 2
3 49140-003 Screw Gasket 2
4 49140-004 Motor Output Gear 1
5 49140-005 Thumb Lock Pins 2
6 49140-006 Motor Sheath 1
No. Part No. Description Qty.
7 49140-007 Torque Spring 1
8 49140-008 Lock Button 1
9 49140-009 Motor 1
10 49140-010 Front Housing, Right 1
11 49140-011 Rear Housing, Right 1
12 49140-012 Screw, ST3×14 5
13 49140-013 Screw, ST3×12 3
14 49140-014 Battery 1
15 49140-015 Flashlight Switch 1
16 49140-016 Flashlight PCB 1
17 49140-017 Alignment Piece 1
18 49140-018 Flashlight Reflector 1
19 49140-019 Flashlight Cover 1
20 49140-020 Trigger 1
21 49140-021 Directional Switch 1
22 49140-022
USB Charger, Micro
USB
1
23 49140-023 Front Housing, Left 1
24 49140-024 Rear Housing, Left 1
25 49140-025 Front LED Light 1
26 49140-026 Power Switch 1
27 49140-027 Primary PCB 1
NOTE: All parts may not be available for purchase or replacement.
Call 1-800-232-1195 with questions.
