EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 56203i-005.1
NEMA 5-20R 120V AC
Duplex Outlet
1
2 56203i-005.2 DC 12V Outlet 1
3 56203i-005.3 USB Outlet 1
4 56203i-005.4 Eco-Mode Switch 1
5 56203i-005.5 Reset Button 1
6 56203i-005.6 DC Breaker, 8A 1
7 56203i-005.7 Oil Level LED, Yellow 1
8 56203i-005.8 Overload LED, Red 1
9 56203i-005.9 Output LED, Green 1
10 56203i-005.10 Nut, M6 1
11 56203i-005.11 Locking Washer, 6mm 1
12 56203i-005.12 Flat Washer, 6mm 1
CONTROL PANEL
NO. PART NO. DESCRIPTION QTY.
13 56203i-005.13 Bolt, M6x20 1
14
56203i-
005.14B
Parallel Socket, Black 1
15 56203i-005.15 Washer, 6mm 1
16
56235iX-
005.16
Nut, M5 1
17
56235iX-
005.17
Toothed Washer, 5mm 1
18
56235iX-
005.18
Flat Washer, 5mm 1
19
56235iX-
005.19
CO Sensor LED 1
20
56203i-
005.14R
Parallel Socket, Red 1
37
To Next Page
