Wen 56310i

EXPLODED VIEW AND PARTS LIST
Item Stock # Description Qty
FIG12-1 56310i-1201 BOLT 8
FIG12-2 56310i-1202 FRAME ASSY, ENGINE(RIGHT) 1
FIG12-3 56310i-1203 FRAME ASSY, ENGINE(LEFT) 1
FIG12-4 56310i-1204 LASSO COMP. 2
FIG12-5 56310i-1205 SPRING 2
FIG12-6 56310i-1206 PIN 2
FIG12-7 56310i-1207 CROSS-HEAD SCREW 2
FIG12-8 56310i-1208 BUSH 1
FIG12-9 56310i-1209 BLOCK, CONTROL ARM LIMITED 1
FIG12-10 56310i-1210 LASSO SUPPORT 1
FIG12-11 56310i-1211 PIN 1
FIG12-12 56310i-1212 RUBBER MAT 1
FIG12-13 56310i-1213 KNOB 1
FIG12-14 56310i-1214 CONNECTION BOARD, FRAME 1
FIG12-15 56310i-1215 CONNECTION BOARD, FRAME 1
FIG12-16 56310i-1216 BOLT 4
FIG12-17 56310i-1217 CROSS-HEAD SELF-TAPPING SCREW 2
FIG12-18 56310i-1218 CLIP 1
FIG.12 FRAME
