Wen 56310i

EXPLODED VIEW AND PARTS LIST
Item Stock # Description Qty
FIG15-1 56310i-1501 STRIP, SHROUD SEAL 1
FIG15-2 56310i-1502 COVER, MUFFLER OUTER 1
FIG15-3 56310i-1503 CROSS-HEAD SELF-TAPPING SCREW 9
FIG15-4 56310i-1504 MUFFLER INSULATION GASKET 1
FIG15-5 56310i-1505 COVER, MUFFLER SIDE 1
FIG15-6 56310i-1506 CROSS-HEAD SCREW AND WASHER COMP. 6
FIG15-7 56310i-1507 STRIP, SHROUD SEAL 1
FIG.15 SHROUD
