PARTS LIST
12
Item Stock # Description Item Stock # Description
1 61720-001 SCREW 37 61720-037 O-RING 15×1.9
2 61720-002 BUSHING 38 61720-038 TRIGGER VALVE GUIDE
3 61720-003 EXHAUST COVER 39 61720-039 TRIGGER SPRING
4 61720-004 SEAL 40 61720-040 SPRING PIN
5 61720-005 SCREW 41 61720-041 RAIL
6 61720-006 SPRING WASHER 42 61720-042 PIN
7 61720-007 CYLINDER CAP 43 61720-043 TRIGGER
8 61720-008 GASKET 44 61720-044 WASHER
9 61720-009 LENGTHEN LOOP 45 61720-045 PLATE
10 61720-010 VALVE SEAL 46 61720-046 SCREW
11 61720-011 SPRING 47 61720-047 FRONT PLATE
12 61720-012 O-RING 15.7×2 48 61720-048 LATCH ASSEMBLY
13 61720-013 O-RING 38.8×3 49 61720-049 SPRING PIN
14 61720-014 O-RING 33.5×3.5 50 61720-050 SPRING PIN
15 61720-015 VALVE 51 61720-051 SCREW
16 61720-016 STOPPED WASHER 52 61720-052 DRIVE GUIDE
17 61720-017 O-RING 50.5×2.5 53 61720-053 SPRING PIN
18 61720-018 COLLAR 54 61720-054 MOVABLE MAGAZINE
19 61720-019 O-RING 28.3×3 55 61720-055 LOCK SPRING
20 61720-020 PISTON ASSEMBLY 56 61720-056 LOCK
21 61720-021 O-RING 36.3×2.5 57 61720-057 PIN
22 61720-022 CYLINDER 58 61720-058 FEEDER SHOE
23 61720-023 BUMPER 59 61720-059 SPRING
24 61720-024 BODY 60 61720-060 SPRING RETAINER
25 61720-025 JOINT GUIDE 61 61720-061 SCREW
26 61720-026 SAFE GUIDER GUIDE 62 61720-062 MAGAZINE SUPPORT
27 61720-027 SPRING 63 61720-063 STOPPED PIECE
28 61720-028 SAFE BRACKET A 64 61720-064 FIXED MAGAZINE
29 61720-029 SAFE BRACKET B 65 61720-065 SCREW
30 61720-030 SAFE BRACKET C 66 61720-066 SUPPORT
31 61720-031 SPRING PIN 67 61720-067 NUT
32 61720-032 SEAL 68 61720-068 SCREW
33 61720-033 TRIGGER VALVE HEAD 69 61720-069 SOFT GRIP SLEEVE
34 61720-034 STEM SPRING 70 61720-070 O-RING 40.2×2.3
35 61720-035 O-RING 5.5×1.5 71 61720-071 END CAP
36
61720-036 TRIGGER VALVE STEM
72
61720-072
AIR PLUG
To Next Page
