No. Part No. New Description Qty
1 90228-001 Screw M4X6 4
2 90228-003 Base Cover 1
3 90228-012 Screw M4X8 2
4 90228-015 Lock Washer (4) 2
5 90228-004 Self-tapping Screw ST4.2X10 2
6 90228-006 Disc Cover 1
7 90228-007 Disc Paper 1
8 90228-008 Inner Hex Screw M6X16 1
9 90228-010 Disc 1
10 90228-011 Disc Guard 1
11 90228-022 Switch Box 1
12 90228-012 Screw M5X8 7
13 90228-062 Screw Assembly M5X25 3
14 6502-051 Belt Tension Lever 1
15 6502-048 Bushing 1
16 90228-058 Screw Assembly M5X16 1
17 90228-017 Base 1
18 6502-018 Power Cord Clip 1
19 90228-022 Switch Box Cover 1
20 90228-020 Screw ST2.9X30 1
21 90228-021 Relay 1
22 6502-050 Spring 1
23 6502-039 Cotter Pin 1
24 6502-016 Pin 5x10 1
25 6502B-125 Screw M4x8 1
26 6502B-126 Screw M4X12 3
27 6502B-127 Hex Nut M5 1
28 90228-028 Capacitor 1
29 90228-029 Capacitor Support 1
30 90228-047 Screw M5x16 1
31 90228-031 Hex Bolt Assembly M6X12 3
32 90228-032 Big Flat Washer (6) 3
33 90228-033 Work Table Support 1
34 90228-034 Miter Gauge Knob 1
35 90228-035 Work Table 1
36 6502-036 Miter Gauge Bar 1
37 6502-037 Miter Gauge Pointer 1
38 6502-038 Miter Gauge 1
39 90228-024 Switch 1
40 90228-037 Tension Spring 1
41 90228-038 Bushing 2
42 90228-039 Belt Tension Support 1
43 6502-043 Retaining Ring D12 2
No. Part No. New Description Qty
44 6502-044 Bearing 4
45 6502-045 Idler Drum 1
46 6502-046 Idler Shaft 1
47 6502B-147 Screw M5x20 2
48 90228-077 Switch Plate 1
49 6502B-149 ScrewST2.9x8 2
50 6502-091 Circuit Breaker 8A 1
51 90228-076 Belt 1
52 90228-080 Inner Hex Screw Assembly M8X16 2
53 90228-075 Belt Frame Support 1
54 90228-058 Screw M5X16 1
55 90228-054 Bearing Base 1
56 90228-048 Belt Tracking Knob 1
57 90228-050 Rubber Spring 1
58 90228-051 Belt Tracking Spring 1
59 90228-052 Belt Support 1
60 90228-053 Work Stop 1
61 6502B-185
Driving Drum & Shaft
Assembly
1
62 6502-062 Inner Hex Screw M8X12 2
63 6502-063 Driving Shaft 1
64 90228-054 Bearing Cap 1
65 90228-055 Belt Support Cover 1
66 6502B-166 Screw Assembly M5X12 3
67 6502B-167 V-groove Belt Guard Cover 1
68 90228-058 Screw Assembly M5X16 2
69 6502B-169 Driving Pulley 1
70 6502B-170 V-groove Belt 155J 1
71 6502B-171 Driven Pulley 1
72 90228-064 Screw Assembly M6X25 3
73 90228-065 Inner Hex Screw M8X25 1
74 90228-066 V-groove Belt Guard 1
75 90228-067 Hex Nut M8 1
76 90228-072 Power Cord 1
77 6502-023 Strain Relief 1
78 6502B-178 Motor Assembly 1
79 90228-040 Screw M5X20 2
80 90228-073 Dust Collection Cover 1
81 90228-046 Hex Bolt Assembly M6X20 3
82 6502B-182 Hex Wrench M6X90X32 1
83 6502B-183 V-groove Belt Guard Support 1
84 6502B-184 Inner Hex Screw Assembly M8X30 1
EXPLODED VIEW & PARTS LIST
19
To Next Page
