EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 90225-001 Hex Nut M8 1
2 90225-002 Upper Spindle Washer 1
3 90225-003 Sander Sleeve 1
4 90225-004 Rubber Spindle 1
5 90225-005 Throat Plate 1
6 90225-006 Lower Spindle Washer 1
7 90225-007 Cast Iron Table 1
8 90225-008 Dust Washer 1
9 90225-009 Dust Cover 1
10 90225-010 Washer 5 5
11 90225-011 Spring Washer 5 5
12 90225-012 Screw 5x12 5
13 90225-013 Belt 1
14 90225-014 Belt II 1
15 90225-015 Belt Wheel 1
16 90225-016 Spring Washer 2
17 90225-017
Tension Roller Assem-
bly
1
18 90225-018 Screw 4.2x13 4
19 90225-019
Orientation Plate
Assembly
1
20 90225-020 Screw 4.2x22 4
21 90225-021 Washer 6 4
22 90225-022 Spring Washer 6 4
23 90225-023 Screw 6x16 4
24 90225-024 Cord Clamp 1
25 90225-025 Screw 4.2x15 2
26 90225-026 Bearing 6001zz 1
27 90225-027 Spring Washer 1
28 90225-028 Armature Assembly 1
29 90225-029 Bearing 608zz 1
30 90225-030 Connection Plate 1
31 90225-031 Field Assembly 1
No. Part No. Description Qty.
32 90225-032 Rear Cover 1
33 90225-033 Brush Holder 2
34 90225-034 Carbon Brush 2
35 90225-035 Brush Spring 2
36 90225-036 Cord Clamp 2
37 90225-037 Washer 4 4
38 90225-038 Screw 4.2x13 4
39 90225-039 Washer 4 2
40 90225-040 Screw 4.2x110 2
41 90225-041 Screw 4.2x22 4
42 90225-042 Bearing Cover 1
43 90225-043 Felt 1
44 90225-044 Rubber Washer 1
45 90225-045 Bearing 6203zz 1
46 90225-046 Bearing Support 1
47 90225-047 Screw 4.2x15 4
48 90225-048 Bearing Sleeve 1
49 90225-049 Spring 1
50 90225-050 Spring Washer 2
51 90225-051 Spindle Washer 2
52 90225-052 Screw 4.2x13 4
53 90225-053 Wheel Plate 1
54 90225-054 Wheel 1 1
55 90225-055 Spindle 1
56 90225-056 Pin 1
57 90225-057 Wheel 2 1
58 90225-058 Bearing Sleeve 1
59 90225-059 Wheel Plate 1
60 90225-060 Screw 4.2x13 4
61 90225-061 Screw 4.2x13 4
62 90225-062 Bearing Support 1
63 90225-063 Bearing 6203zz 1
17
To Next Page
