No. Part No. Description Qty.
64 90225-064 Rubber Washer 1
65 90225-065 Felt 1
66 90225-066 Wheel Support 1
67 90225-067 Wire Assembly 1 1
68 90225-068 Wire Assembly 2 1
69 90225-069 Rectifier 1
70 90225-070 Screw 4.2x19 1
71 90225-071 Wire Assembly 3 1
72 90225-072 Wire Assembly 4 1
73 90225-073 Power Cord 1
74 90225-074 Cord Clamp 1
75 90225-075
Switch Orientation
Plate
1
76 90225-076 Housing Base 1
78 90225-078 Logo Label 1
79 90225-079 Switch Orientation 1 1
80 90225-080 Switch 1
81 90225-081 Switch Orientation 2 1
82 90225-082
Switch Assistant Orien-
tation
1
83 90225-083 Screw 4x16 4
84 90225-084 Warning Label 1 1
85 90225-085 Cord Clamp 1
86 90225-086 Screw 4.2x15 2
87 90225-087 Thread 2
88 90225-088 Screw 4.2x10 2
89 90225-089 Rubber Foot 4
90 90225-090 Washer 6 6
91 90225-091 Spring Washer 6 6
No. Part No. Description Qty.
92 90225-092 Screw 6x16 6
93 90225-093 Bottom Plate 1
94 90225-094 Screw 4.2x13 6
95 90225-095 Warning Label 2 1
96 90225-096 1/2” Throat Plate
97 90225-097 3/4” Throat Plate 1
98 90225-098 1” Throat Plate 1
99 90225-099 1-1/2” Throat Plate 1
100 90225-100 2” Throat Plate 1
101 90225-101 3” Throat Plate 1
102 90225-102
1/2” Sanding Sleeve
(80 Grit)
1
103 90225-103
3/4” Sanding Sleeve
(80 Grit)
1
104 90225-104
1” Sanding Sleeve
(80 Grit)
1
105 90225-105
1-1/2” Sanding Sleeve
(80 Grit)
1
106 90225-106
2” Sanding Sleeve
(80 Grit)
1
107 90225-107
3” Sanding Sleeve
(80 Grit)
1
108 90225-108 3/4” Rubber Spindle 1
109 90225-109 1” Rubber Spindle 1
110 90225-110 1-1/2” Rubber Spindle 1
111 90225-111 2” Rubber Spindle 1
112 90225-112 3” Rubber Spindle 1
EXPLODED VIEW & PARTS LIST
