Wen 6559 User Manual

EXPLODED VIEW & PARTS LIST
21
No. Part No. Description Qty.
1 6559-001
Fence Sliding Handle,
M8x32
1
2 6559-002 Flat Washer, Ø8 1
3 6559-003 Fence Bracket 1
4 6559-004 Hex Head Bolt, M6x40 1
5 6559-005 Hex Nut, M6 1
6 6559-006 Fence Bevel Handle, M8 1
7 6559-007 Flat Washer, Ø8 1
8 6559-008 Bolt 1
9 6559-009 Fence Angle Guide 1
10 6559-010 Flat Washer, Ø5 1
11 6559-011 Phillips-Head Screw, M5x8 1
12 6559-012 Socket Head Screw, M5x20 2
13 6559-013 Hex Nut, M5 2
14 6559-014 Angle Support 1
15 6559-015 Flat Head Screw, M6x10 4
16 6559-016 Hex Nut, M6 4
17 6559-017 Fence 1
18 6559-018 Fence Left End Cover 1
19 6559-019 Fence Right End Cover 1
20 6559-020
Socket Pan Head Screw,
M6x20
2
21 6559-021 Fence Sliding Base 1
22 6559-022 Square Nut, M8 1
23 6559-023 Retaining Ring, Ø12 1
24 6560-043 Ball Bearing, 6201-2Z 2
25 6559-025 Body with Outfeed Table 1
26 6559-026 Set Screw, M6x16 4
27 6559-027 Flat Washer, Ø6 4
28 6559-028 Lock Washer, Ø6 4
29 6559-029 Socket Head Screw, M6x30 4
30 6559-030 Cushion 1
31 6559-031 Infeed Table 1
32 6560-038 Connection Plate 4
33 6559-033 Pin 4
34 6559-034 C-clip, Ø6 4
35 6560-040 Pin 4
36 6559-036 Socket Head Screw, M5x10 8
No. Part No. Description Qty.
37 6559-037 Lock Washer, Ø5 8
38 6559-038 Connection Bracket 4
39 6559-039 Table Support Plate 1
40 6559-040 Set Screw, M6x30 1
41 6559-041 Hex Nut, M6 1
42 6560-047 Support Plate 1
43 6559-043 Flat Washer, Ø5 2
44 6559-044 Lock Washer, Ø5 2
45 6559-045 Socket Head Screw, M5x10 2
46 6560-050 Infeed Screw 1
47 6560-051 Infeed Adjustment Knob 1
48 6559-048 Flat Washer, Ø5 1
49 6559-049 Socket Head Screw, M5x10 1
50 6559-050 Set Screw, M6x30 1
51 6559-051 Hex Nut, M6 1
52 6560-096 Dust Chute 1
53 6559-053 Phillips-Head Screw, M6x25 1
54 6559-054 Socket Head Screw, M5x14 1
55 6559-055 Lock Washer, Ø5 1
56 6559-056 Flat Washer, Ø5 1
57 6560-094 Chip Collector 1
58 6559-058 Cushion 1
59 6559-059 Flat Washer, Ø5 4
60 6559-060 Cord Clamp 1
61 6559-061 Pan Head Screw, M5x16 3
62 6560-095 Chip Exhaust 1
63 6560-100 Fan 1
64 6559-064 Mounting Plate 1
65 6559-065 Flat Washer, Ø5 2
66 6559-066 Lock Washer, Ø5 2
67 6559-067 Socket Head Screw, M5x14 2
68 6559-068 Screw, ST4.2x9.5 6
69 6560-105 Fan Shaft Axle 1
70 6560-106 Ball Bearing, 6000-2Z 2
71 6560-107 Spacer 1
72 6559-072 Retaining Ring, Ø26 1
