Wen 6559 User Manual

EXPLODED VIEW & PARTS LIST
22
No. Part No. Description Qty.
73 6559-073 Fan Pulley 1
74 6559-074 Set Screw, M6x8 1
75 6559-075 Shaft 1
76 6560-084 Cutterhead 1
77 6560-085 Gib Screw 4
78 6559-078 Set Screw, M6x10 3
79 6559-079
Socket Pan Head Screw,
M6x16
8
80 6560-082 Blade Clamp 2
81 6560-083 Blade 2
82 6559-082 Drive Pulley 1
83 6559-083 Set Screw, M6x8 2
84 6560-079 Drive Belt, V-groove, 170J 1
85 6560-091 Fan Belt, V-groove, 140J 1
86 6559-086 Cover 1
87 6559-087 Flat Head Screw, M5x10 2
88 6560-075 Blade Guard 1
89 Blade Guard Flange 1
90 6560-074 Bumper 1
91 6559-091 Pan Head Screw, M5x10 1
92 6559-092 Pin 1
93 6560-071 Spring 1
94 6559-094 Spacer 1
95 6560-076 Spring 1
96 6559-096 Hex Nut, M5 1
97 6559-097 Flat Washer, Ø5 1
98 6559-098 Socket Head Screw, M5x14 1
99 6559-099 Cutting Depth Cover 1
100 6559-100 Cutting Depth Window 1
101 6559-101 Flat Head Screw, M3x6 1
102 6559-102 Cutting Depth Pointer 1
103 6559-103 Cutting Depth Scale 1
104 6559-104 Crank 1
105 6559-105 Pan Head Screw, M4x8 1
106 6559-106 Flat Washer, Ø4
107 6559-107 Pan Head Screw, M5x10 2
No. Part No. Description Qty.
108 6559-108 Connecting Bracket 1
109 6559-109 Cutting Depth Housing 1
110 6559-110 Spring 1
111 6559-111 Depth Gauge 1
112 6559-112 Serrated Washer, Ø5 2
113 6559-113 Flat Washer, Ø5 2
114 6559-114 Lock Washer, Ø5 2
115 6559-115 Pan Head Screw, M5x10 2
116 6559-116 Power Cord 1
117 6559-117 Strain Relief 1
118 6560-062 Motor 1
119 6559-119 Motor Support 1
120 6559-120 Flat Washer, Ø6 4
121 6559-121 Lock Washer, Ø6 4
122 6559-122 Socket Head Screw, M6x16 4
123 6559-123 Flat Washer, Ø5 4
124 6559-124 Lock Washer, Ø5 4
125 6559-125 Socket Head Screw, M5x14 4
126 6560-063 Motor Pulley 1
127 6559-127 Base 1
128 6559-128 Foot 4
129 6559-129 Flat Washer, Ø5 8
130 6559-130 Socket Head Screw, M5x10 8
131 6559-131 Bottom Cover 1
132 6559-132 Flat Washer, Ø4 6
133 6559-133 Screw, ST4.2x9.5 6
134 6559-134 ON/OFF Switch 1
135 6560-123 Spring 1
136 6560-124 Filter bag 1
137 6560-121 Push stick 1
138 6560-122 Push block 1
139 6559-139 Hex wrench, M4 1
140 6559-140 Set Screw M5x6 4
141 6560-061 Carbon Brush 2
142
6560-
062.1
Carbon Brush Cap 2
