Wen 94810 User Manual

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 94810-001 Polishing Plate 1
2 94810-002 Output Shaft 1
3 94810-003 Screw M5x14 4
4 94810-004 Washer Ø5 8
5 94810-005 Connecting Plate 1
6 94810-006
Bearing 6002
Ø32xØ15x09
1
7 94810-007 Spring Ring Ø4 3
8 94810-008 Fixing Plate 2
9 94810-009 Screw M4x10 6
10 94810-010 Gear Wheel 1
11 94810-011 Woodruff Key 1
12 94810-012 Ring Ø17xØ12.2x0.3 1
13 94810-013 Axis Spring Ø12 2
14 94810-014
Needle Bearing
Ø14xØ8x10
1
15 94810-015 Cover 1
16 94810-016
Self-Tapping Screw
ST5x30
4
17 94810-017 Axis Spring Ø8 1
18 94810-018 Spindle Lock Spring 1
19 94810-019 Spindle Lock Button 1
20 94810-020 Side Handle M10 1
21 94810-021
Bearing 6001Z
Ø28xØ12x8
1
22 94810-022 Rotor Assembly 1
23 94810-023 Bearing 608 Ø22xØ8x7 1
24 94810-024 Bearing Cap 1
25 94810-025 Motor Cover 1
No. Part No. Description Qty.
26 94810-026
Self-Tapping Screw
ST4x55
2
27 94810-027 Stator Assembly 1
28 94810-028
Heat-Shrinkable Tube
Ø3
1
29 94810-029 Terminal 2
30 94810-030 Power Cord with Plug 1
31 94810-031 Cord Sheath 1
32 94810-032 Cord Fixing Plate 1
33 94810-033 Left Handle 1
34 94810-034 Terminal Block 2
35 94810-035 Control Panel Cover 1
36 94810-036 Rubber Plug M10 2
37 94810-037 Housing 1
38 94810-038 Subplate 2
39 94810-039 Carbon Brush 2
40 94810-040 Carbon Brush Holder 2
41 94810-041
Self-Tapping Screw
ST3x10
4
42 94810-042 PCB 1
43 94810-043 Display Lens 1
44 94810-044 Left Control Button 1
45 94810-045 Right Control Button 1
46 94810-046 Switch Snap 1
47 94810-047
Self-Tapping Screw
ST3x8
3
48 94810-048 Copper Strips 6
49 94810-049 Right Handle 1
50 94810-050
Self-Tapping Screw
ST4x16
7
15
