Wen DF8000X

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 DF8000X-001ASM
Control Panel
Assembly
1
2 DF8000X-002
NEMA L14-30R
120V/240A 30A
Receptacle
1
3 GN5600-008
NEMA 5-20R 120V
AC 20A Duplex
Receptacle
2
4 GN5600-010
Grounding Lug
Assembly
1
5 GN5600-015 AC Breaker, 20A 2
6 GN5600-005
NEMA TT-30R 120V
AC 30A RV
Receptacle
1
7 DF8000X-007
12V DC Automotive
Receptacle
1
8 DF5600X-008 Fuel Selector Switch 1
9 DF8000X-009 DC Breaker, 8.3A 1
10 GN5600-014
Low Oil Indicator
Light
1
11 GN5600-004 Multi-meter 1
12 DF5600X-010 Engine Switch 1
13 DF5600X-007 Indicator LED 1
14 GN5602X-013
CO Sensor Indicator
Light
1
15 DF8000X-015 Panel 1
16 GN5600-003
Phillips Pan Head
Screw, M5x12
6
17 DF8000X-017 AC Breaker, 30A 1
18 DF8000X-018
Voltage Selector
Switch
1
19 DF8000X-019 AC Breaker, 25A 2
20 DF8000X-020
Control Panel Hous-
ing
1
21 GN5600-001
Phillips Pan Head
Screw, M6x10
4
22 DF8000X-022 Control Panel Cover 1
23 DF5600X-020
Pan Head Screw,
M4x18
2
GENERATOR
NO. PART NO. DESCRIPTION QTY.
24 GN5602X-019 CO Sensor Module 1
25 GN5600-021 Nut, M8 2
26 DF8000X-026 Muffler Gasket 1
27 DF8000X-027 Muffler 1
N.P. DF8000X-027.1 Spark Arrestor 1
28 GN5600-087
Flanged Hex Bolt,
M8x16
2
29 DF8000X-029 Frame Assembly 1
30 DF8000X-030 Fuel Hose, 9.6x440 1
31 GN5600-030 Hose Clamp, 10mm 2
32 GN5600-041 Combination Clamp 1
33 DF8000X-033 Carbon Tank Hose 1
34 GN5600-040 Protective Sleeve 1
35 GN5600-031 Breather Valve 1
36 DF8000X-036 Fuel Gauge 1
37 GN5600-034 Fuel Tank Cap 1
38 DF8000X-038 Fuel Tank Filter 1
39 GN5600-035
Flanged Hex Bolt,
M6x25
4
40 GN5600-036 Flat Washer, 6mm 4
41 GN5600-037
Fuel Tank Vibration
Isolation Sleeve
4
42 GN5600-038
Fuel Tank Vibration
Isolation Pad
4
43 DF8000X-043 Fuel Tank 1
44 GN5600-043 Fuel Valve 1
45 GN5600-081
Flanged Hex Bolt,
M8x48
1
46 GN5600M-060 Handle Bracket 1
47 GN5600M-059
Flanged Hex Bolt,
M8x16
4
48 GN5600-079 Nut, M8 1
49 GN5600-082 Pin 1
50 DF5600X-050 Handle Grip 1
51 GN5600M-056 Handle 1
52 DF8000X-052 Alternator Assembly 1
53 DF8000X-053 Carbon Brushes 1
54 DF8000X-054 Wiring Terminal 1
