Wen DF8000X

EXPLODED VIEW & PARTS LIST
GENERATOR
NO. PART NO. DESCRIPTION QTY.
55 GN5600-069
Flanged Hex Bolt,
M5x6
7
56 DF8000X-056 Alternator Bracket 1
57 DF8000X-057
Washer, 6mm x
10mm
1
58 DF8000X-058 Bolt, M6x16 4
59 DF8000X-059
Automatic Voltage
Regulator (AVR)
1
60 DF8000X-060 Alternator Cover 1
61 DF5600X-070
Flanged Hex Bolt,
M5x12
5
62 DF8000X-062 Grounding Wire 1
63 GN5600-060 Lock Washer, 6mm 1
64 GN5602X-063 Battery Strap 1
65 DF8000X-065
Battery, 12V 1.6Ah,
Li-ion
1
66 DF8000X-066
Battery Quick-
Connector Wiring
Harness
1
67 GN5600-047
Flanged Hex Bolt,
M6x40
4
68 GN5600M-041 Foot Support 2
69 GN5600M-042 Foot Support Pad 2
70 DF8000X-070
Secondary LPG
Regulator
1
71 DF5600X-072 Hose Clamp 1
72 DF8000X-072 LPG Tube 1
73 GN5600-091
Flanged Hex Nut,
M6
4
NO. PART NO. DESCRIPTION QTY.
74 GN5600M-043 Axle Pin 2
75 GN5600M-044 Wheel 2
76 GN5600-051 Flat Washer 2
77 GN5600-050 Cotter Pin 2
78 GN5600-045
Flanged Hex Nut,
M8
6
79 GN5600-046 Engine Mount 1
80 GN5600-056
Flanged Hex Bolt,
M8x32
4
81 DF8000X-081 Engine Cover 1
82 GN5600-018 Dowel Pin 2
83 DF8000X-083ASM Engine Assembly 1
84 GN5600-027 Bolt, M6x12 1
85 GN5600-087
Flanged Hex Bolt,
M8x16
3
86 GN5600-085
Flanged Hex Bolt,
M8x35
2
87 DF8000X-087
Flanged Hex Bolt,
M8x35
2
88 DF8000X-088 Shipping Bracket 1 1
89 DF8000X-089 Shipping Bracket 2 1
90 DF5600X-090
Primary LPG
Regulator Hose
1
91 DF8000X-091 Support 1
92 DF8000X-092
Flanged Hex Bolt,
M5x184
2
93 DF8000X-093
Flanged Hex Nut,
M10
4
94 DF8000X-094 Charger
95 DF8000X-095 Controller
