Wen DF8000X

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 DF8000X-101
Flanged Hex Bolt,
M6x20
6
2 DF8000X-102
Cylinder Head
Cover
1
3 DF8000X-103 Oil Filter 1
4 DF8000X-104
Breather Plate
Cover Gasket
1
5 DF8000X-105
Breather Plate
Cover
1
6 GN5600-106
Flanged Hex Bolt,
M5x10
2
7 DF8000X-107
Cylinder Head
Cover Gasket
1
8 DF8000X-108
Flanged Hex Bolt,
M5x10
2
9 DF8000X-109
Cylinder Head
Cowling
1
10 DF8000X-110 Rocker Arm Shaft 2
11 DF8000X-111
Rocker Arm
Assembly
2
12 DF8000X-112 Push Rod 2
13 DF8000X-113 Valve Lifter 2
14 DF8000X-114
Flanged Hex Bolt,
M10x80
4
15 GN5600-122 Stud, M8x34 2
16 DF8000X-116 Valve Rotator 2
17 DF8000X-117 Valve Lock 4
18 DF8000X-118
Valve Spring
Retainer
2
19 DF8000X-119 Valve Spring 2
20 DF8000X-120 Valve Stem Seal 1
21 DF8000X-121 Valve Set 1
22 DF8000X-122
Spark Plug, Torch
F7RTC (NGK
BPR7ES)
1
23 DF8000X-123 Cylinder Head 1
24 DF8000X-124 Stud, M6/8x102 2
25 DF8000X-125
Carburetor
Insulator Gasket
1
ENGINE
NO. PART NO. DESCRIPTION QTY.
26 DF8000X-126
Carburetor
Insulator
1
27 DF8000X-127 Carburetor Gasket 1
28 DF8000X-128 Carburetor 1
29 GN5600-129 Hose Clamp 1
30 DF8000X-130 Fuel Tube 1
31 DF8000X-131 Governor Rod 1
32 DF8000X-132
Throttle Return
Spring
1
33 DF8000X-133 Hose Clamp 2
34 DF8000X-134 Air Filter Gasket 1
35 DF8000X-135 Breather Tube 1
36 GN5600-136
Flanged Hex Nut,
6mm
2
37 DF8000X-137 Air Filter Element 1
38 DF8000X-138 Air Filter Assembly 1
39 DF8000X-139
Cylinder Head
Gasket
1
40 DF8000X-140
Piston Ring
Assembly
1
41 DF8000X-141 Piston 1
42 DF8000X-142 Piston Pin 1
43 DF8000X-143 Piston Pin Clip 2
44 DF8000X-144
Connecting Rod
Assembly
1
45 DF8000X-145 Dowel Pin 2
46 DF8000X-146
Flanged Hex Bolt,
M8x35
6
47 DF8000X-147 Oil Seal 2
48 DF8000X-148 Crankcase Cover 1
49 DF8000X-149
Oil Dipstick
Assembly
1
50 DF8000X-150 Governor Gear 1
51 DF8000X-151 Dowel Pin 2
52 DF8000X-152
Crankcase Cover
Gasket
1
53 DF8000X-153
Flanged Hex Bolt,
M6x10
3
54 GN5600-154 Crankshaft Cowling 1
43
