Wen DF8000X

EXPLODED VIEW & PARTS LIST
ENGINE
NO. PART NO. DESCRIPTION QTY.
55 DF8000X-155 Camshaft Assembly 1
56 DF8000X-156
Crankshaft
Assembly
1
57 GN5600-101
Flanged Hex Bolt,
M6x16
1
58 DF8000X-158 Oil Level Sensor 1
59 DF8000X-159 Governor Bracket 1
60 DF8000X-160
Governor Gear
Assembly
1
61 DF8000X-161 Governor Spring 1
62 DF8000X-162 Clip 1
63 DF8000X-163 Washer 1
64 DF8000X-164 Governor Arm 1
65 DF8000X-165 Crankcase 1
66 DF8000X-166 Drain Bolt, M14x15 2
67 DF8000X-167 Washer 2
68 DF8000X-168
Ignition Coil
Assembly
1
69 GN5600-167
Flanged Hex Bolt,
M6x25
2
NO. PART NO. DESCRIPTION QTY.
70 DF8000X-170 Flywheel 1
71 DF8000X-171 Fan 1
72 DF8000X-172 Starter Cup 1
73 DF8000X-173
Flanged Hex Nut,
M16-1.5
1
74 DF8000X-174 Fan Cover 1
75 DF8000X-175 Recoil Starter 1
76 DF8000X-176
Recoil Starter
Assembly
1
77 DF8000X-177 Dowel Pin 2
78 DF8000X-178
Starter Motor
Assembly
1
79 DF8000X-179
Flanged Hex Bolt,
M6x35
2
80 GN5600-175 Clip 1
81 DF5600X-178 Hose Clamp 1
82 DF8000X-182 Breather Tube 1
83 GN5600-177 Oil Alert Module 1
