27
USING YOUR GENERATOR
CIRCUIT BREAKERS
In addition to the reset button that protects the generator’s main
circuit, the circuit breaker (Fig. 21) protects the NEMA 5-20 out-
lets. The 20-amp AC circuit breaker will activate when the NEMA
5-20 outlets exceed 20A. When the circuit breaker activates,
turn off and disconnect the device from its respective outlet, and
press the circuit breaker to reset.
Fig. 21
