Wen DG4500iX User Manual

43
EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 DG4500iX-001 Bolt, M6x15 7
2 DG4500iX-002 Inverter Cover 1
3 DF430X-065 Screw, ST4.2x16 6
4 DG4500iX-004 CO Sensor Module 1
5 DG4500iX-005
Control Panel
Assembly
1
6 DG4500iX-006
CO Sensor Engine
Control Module
1
7 56500-017 Bolt, M6x25 7
8 DG4500iX-008 Inverter 1
9 DG4500iX-009 Bolt, M6x30 1
10 DG4500iX-010 Battery Charger 1
11 DG4500iX-011 Bolt, M6x10 3
12 56500-007 Circlip 2
13 56500-008 Wheel 2
14 DF430X-010 Pin, Ø16x85 2
15 DF430X-072 Clamp 2
16 DG4500iX-016 LPG Tube (9x17x92) 1
17 56500-052 Hose Clamp, 8mm 5
18 DG4500iX-018 Clip 1
19 DG4500iX-019
Secondary LPG
Regulator
1
20 DF430X-074 LPG Inlet Cover 1
21 DF430X-075 Screw,M6x10 3
22 56500-1047 Bolt, M6x12 4
23 DF430X-044
Primary LPG
Regulator
1
24 56500-010 Damping Pad 1
25 DF430X-073 Clip 2
26 DG4500iX-026 Left Panel 1
27 56500-049 Carbon Tank 1
28 DG4500iX-028 Clamp 1
29 DG4500iX-029 Carbon Tank Hose 1
30 DG4500iX-030 Screw, M4x10 1
31 DG4500iX-031
Fuel Selector Switch
Knob
1
32 DG4500iX-032 Switch Seat 1
33 DG4500iX-033 Nut, M5 3
GENERATOR
NO. PART NO. DESCRIPTION QTY.
34 DG4500iX-034 Fuel Selector Switch 1
35 DG4500iX-035
Fuel Line Clamp,
16mm
1
36 DG4500iX-036 Frame Assembly 1
37 DG4500iX-037 Fuel Line Sleeve 1
38 DG4500iX-038 Fuel Line (4x8x310) 1
39 DG4500iX-039 Fuel Tank Outlet 1
40 DG4500iX-040 Fuel Tank Assembly 1
N.P. DG4500iX-040.1 Fuel Gauge 1
41 56500-016 Washer, Ø6.5x2xØ25 4
42 DG4500iX-042 Breather Hose 1
43 56500-019 Fuel Gauge Clip 1
44 DG4500iX-044 Fuel Tank Cap 1
45 DG4500iX-045 Electric Start Module 1
46 56500-044 Nut, M6 3
47 56500-001 Handle Sleeve 2
48 DG4500iX-048 Handle 2
49 DG4500iX-049 Handle Pad 2
50 GN6000-005 Bolt, M8x40 2
51 GN6000-003 Nut, M8 2
52 DF430X-063 Washer 4
53 56500-001 Handle Plug 2
54 56500-036 Nut, M8 10
55 DG4500iX-055 Engine Assembly 1
56 DG4500iX-056 Air Filter Bracket 1
57 DG4500iX-057 Bushing, Ø12xØ6x8 1
58 DF430X-060 Bolt, M6x18 2
59 DG4500iX-059
Rear Engine
Mounting Beam
1
60 DG4500iX-060
Bushing,
Ø6.5xØ10x24
3
61 DG4500iX-061 Bolt, M6x35 3
62 DG4500iX-062 Heat Shield 1
63 DG4500iX-063 Right Engine Mount 2
64 DG4500iX-064 Bolt, M8x43 1
65 DG4500iX-065
Front Engine
Mounting Beam
1
66 DG4500iX-066 Left Engine Mount 2
