EXPLODED VIEW & PARTS LIST
GENERATOR
NO. PART NO. DESCRIPTION QTY.
67 DG4500iX-067 Bolt, M8x35 3
68 56500-025 Nut, M8 2
69 DG4500iX-069 Muffler Gasket 1
70 DG4500iX-070 Muffler Assembly 1
71 DG4500iX-071 Muffler Guard 1
72 DG4500iX-072 Bolt, M6x10 5
73 DG4500iX-073
Battery Wiring
Harness
1
74 DG4500iX-074 Battery 1
75 DG4500iX-075 Rubber Pad 1
76 DG4500iX-076 Battery Bracket 1
77 DF430X-057
Support Base
Assembly
1
78 DF430X-058 Support Base 1
79 DF430X-059 Foot 2
NO. PART NO. DESCRIPTION QTY.
80 56500-060 Bolt, M8x16 2
81 DG4500iX-081 Grounding Wire 1
82 56500-011 Clamp, 7.5mm 1
83 GN9500-062
Carburetor Drain
Bolt Gasket
1
84 DG4500iX-084 Bolt, M6x18 1
85 DG4500iX-085 Handle Assembly 1
86 DG4500iX-086 Spark Arrester 1
87 DG4500iX-087 Bolt, M5x12 2
N.P. DG4500iX-HA36
High-Altitude Kit,
3000 - 6000 ft
0
N.P. DG4500iX-HA69
High-Altitude Kit,
6000 - 9800 ft
0
N.P. DG4500iX-418 Hex Wrench, 5mm 1
N.P. DG4500iX-HW Hardware Bag 1
44
