EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 GN9500-101 Bolt, M6x16 7
2 DG4500iX-102 Cylinder Head Cover 1
3 DG4500iX-103 Breather Hose 1
4 DF430X-076
Cylinder Head Cover
Gasket
1
5 DG4500iX-105 Bolt, M8x60 4
6 DF430X-141 Clip 1
7 DG4500iX-107
Rocker Arm
Assembly
2
8 DF430X-080 Rocker Arm Base 1
9 DF430X-082 Valve Locker 4
10 56500-114 Valve Spring Seat 2
11 DF430X-083 Valve Spring 2
12 56500-116 Intake Valve Seal 1
13 DG4500iX-113 Stud, M8x34 2
14 DF430X-100 Exhaust Valve 1
15 56310i-0104
Spark Plug, Torch
F6RTC
(NGK BPR6ES)
1
16 DF430X-101 Intake Valve 1
17 DG4500iX-117
Cylinder Head
Assembly
1
18 DG4500iX-118 Stud, M6x98 2
19 DF430X-088
Carburetor Insulator
Gasket
1
20 DG4500iX-120 Insulator 1
21 DF430X-090 Carburetor Gasket 1
22 DG4500iX-122 Carburetor 1
23 DG4500iX-123 LPG Hose, 9x17x420 1
24 DF430X-139
LPG Hose Clamp,
16mm
1
25 DG4500iX-125 Fuel Line Sleeve 1
26 DG4500iX-126 Clamp, 25mm 1
27 DG4500iX-127 Clamp, 8mm 1
28 DG4500iX-128 Fuel Line, 4x8x325 1
29 DG4500iX-129 Stepper Motor Cover 1
30 DG4500iX-130 Screw, M4x6 4
31 DG4500iX-131 Stepper Motor 1
ENGINE
NO. PART NO. DESCRIPTION QTY.
32 DG4500iX-132 Screw, M4x12 2
33 DG4500iX-133 Stepper Motor Base 1
34 DG4500iX-134 Guide Clamp 1
35 DG4500iX-135 Spring 1
36 DF430X-093 Air Filter Gasket 1
37 DG4500iX-137 Washer, Ø8 2
38 DG4500iX-138 Air Filter Assembly 1
39 DG4500iX-139
Air Filter Base
Assembly
1
40 56500-133 Air Filter Baffle 1
41 56500-134 Air Filter Element 1
42 DF430X-096 Air Filter Cover 1
43 56500-136 Knob 1
44 DG4500iX-144 Nut, M6 2
45 DF430X-081 Shroud 1
46 GN9500-184 Bolt, M6x10 4
47 DG4500iX-147
Cylinder Head
Gasket
1
48 DF430X-098 Pin,Ø10x16 2
49 DG4500iX-149 Piston Ring Set 1
50 DG4500iX-150 Piston Ring 1 1
51 DG4500iX-151 Piston Ring 2 1
52 DG4500iX-152 Oil Ring 1
53 DG4500iX-153 Push Rod 2
54 DG4500iX-154 Valve Tappet 2
55 DG4500iX-155 Piston 1
56 56500-147 Circlip 2
57 DG4500iX-157 Piston Pin 1
58 DF430X-105
Connecting Rod
Assembly
1
59 56500-179
Grounding Bolt,
M10-1.25x15
2
60 56500-180
Washer,
Ø10x1.5xØ16
3
61 DG4500iX-161 Oil Drain Tube 1
62 DG4500iX-162 Oil Sensor 1
63 DF430X-109 Bearing, TM6205 2
64 DG4500iX-164 Crankshaft Assembly 1
46
To Next Page
