EXPLODED VIEW & PARTS LIST
ENGINE
NO. PART NO. DESCRIPTION QTY.
65 DG4500iX-165 Camshaft Assembly 1
66 DG4500iX-166 Crankcase Gasket 1
67 DG4500iX-167 Crankcase Cover 1
68 DF430X-106 Bolt, M8x32 6
69 DG4500iX-169 Dipstick 1
70 56500-156 Pin, Ø8x14 2
71 DF430X-115 Bolt, M6x12 2
72 DG4500iX-172 Top Cover 1
73 DF430X-125 Bolt, M6x20 3
74 56500-178 Clip 1
75 DG4500iX-175 Ignition Coil 1
76 DG4500iX-176 Crankcase 1
77 DG4500iX-177 Trigger Support 1
78 DG4500iX-178 Bolt, M6x12 2
79 DG4500iX-179 Trigger 1
80 DF430X-126
Oil Seal,
Ø25xØ41.25x6
1
81 DG4500iX-181 Lower Shield 1
82 DG4500iX-182 Stator Assembly 1
NO. PART NO. DESCRIPTION QTY.
83 DG4500iX-183 Bolt, M6x50 3
84 DG4500iX-184 Rotor Assembly 1
85 DG4500iX-185 Cooling Fan 1
86 DG4500iX-186 Starter Cup 1
87 56500-188 Nut, M14-1.5 1
88 DG4500iX-188
Recoil Starter
Assembly
1
89 DG4500iX-189
Recoil Starter
Housing
1
90 DG4500iX-190 Recoil Starter 1
91 DG4500iX-191 Washer, Ø6 3
92 DG4500iX-192 Bolt, M6x10 3
93 DG4500iX-193 Bolt, M6x100 3
94 DG4500iX-194 Bolt, M6x14 4
95 DG4500iX-195 Nut, M8 2
96 DG4500iX-196 Exhaust Pipe 1
97 DG4500iX-197 Muffler Gasket 1
98 DG4500iX-198 Bolt, M6x20 1
99 DG4500iX-199 Bolt, M6x15 1
47
