EXPLODED VIEW & PARTS LIST
14
No. Part No. Description Qty.
1 DW6394-001 Sandpaper 1
2 DW6394-002 M6x14 screw 1
3 DW6394-003 Ø6 mm Washer 1
4 DW6394-004 Sanding Pad 1
5 DW6394-005 ST4x10 Screw 1
6 DW6394-006 Ø4 mm Washer 1
7 DW6394-007
Suction Adjustment
Wheel
1
8 DW6394-008 Large Brush Skirt 1
9 DW6394-009 Short Brush Skirt 1
9A DW6394-009A ST3x10 Screw 2
10 DW6394-010 Pressure Block 1
11 DW6394-011 Detailing Segment 1
12 DW6394-012 Pad Housing 1
15A DW6394-015A
Ø34 mm Retaining
Ring
1
16 DW6394-016 Gasket 18 x 28 x 6 1
17 DW6394-017 Pad Output Shaft 1
18 DW6394-018
Ball Bearing CSR-
6001RZL
1
19 DW6394-019 Spring 4
20 DW6394-020
Ø28 mm Retaining
Ring
1
21 DW6394-021
Ø12 mm Retaining
Ring
1
22 DW6394-022 Swivel Head 1
23 DW6394-023 Swivel Pin 1
24 DW6394-024 M6x25 Screw 1
25 DW6394-025 M6 Threaded Pin 2
26 DW6394-026 Lock Nut 1
27 DW6394-027 Ø28 mm Gasket 1
28 DW6394-028
Aluminum Connec-
tion Arm
1
29 DW6394-029 Jacket Pin 2
30 DW6394-030 Head Joint 1
31 DW6394-031 ST4x10 Screw 4
32 DW6394-032 Y Swivel Joint 1
33 DW6394-033 O-ring 14x2 1
34 DW6394-034 M4s35 Screw 1
35 DW6394-035 Tube Clamp 2
No. Part No. Description Qty.
36 DW6394-036 Flexible Shaft 1
37 DW6394-037 Flexible Tube 1
39 DW6394-039 M4x40 Screw 2
40 DW6394-040 M4x10 Screw 2
41 DW6394-041 Aluminum Pipe Joint 1
42 DW6394-042 Thin Joint Connector 1
43 DW6394-043 Screw Joint 1
44 DW6394-044 Transmission Shaft 1
45 DW6394-045
Left Hand Grip
Housing
1
46 DW6394-046
Lower Left Motor
Housing
1
47 DW6394-047 Switch Holder 1
48 DW6394-048 Electrical Switch 1
49 DW6394-049
Lower Switch
Rocker
1
50 DW6394-050 Upper Switch Lock 1
51 DW6394-051 Switch Pin 1
52 DW6394-052 Main Aluminum Pipe 1
53 DW6394-053 Left Bottom Cover 1
54 DW6394-054 Power Cord 1
57 DW6394-057 Governor 1
58 DW6394-058 Shaft Holder 1
59 DW6394-059
Transmission Shaft
Tube
1
60 DW6394-060 Hose Adapter 1
61 DW6394-061 Soft Handle 1
62 DW6394-062 Ø10 Retaining Ring 1
63 DW6394-063 Ø14 Retaining Ring 1
64 DW6394-064 M4x20 Screws 1
65 DW6394-065 Carbon Brush Cover 2
66 DW6394-066 Carbon Brush 2
67 DW6394-067 Carbon Brush Holder 2
67A DW6394-067A
Carbon Brush
Winding
2
68 DW6394-068 Motor Housing 1
69 DW6394-069 Bearing Sleeve 1
70 DW6394-070 Ball Bearing 608NSK 1
71 DW6394-071 Stator 1
72 DW6394-072 ST4x55 Screw 2
