Wen DW6394 User Manual

15
No. Part No. Description Qty.
73 DW6394-073 Motor Cap 1
74 DW6394-074 Rotor 1
75 DW6394-075
Ball Bearing
6000NSK
1
76 DW6394-076 Ø25.8x1.8 O-Ring 1
77 DW6394-077 Gearbox Bottom 1
78 DW6394-078
Ball Bearing CS-
R608Z
1
79 DW6394-079 Double Gear 1
80 DW6394-080
Roller Bearing
HK0810
1
81 DW6394-081
Ball Bearing XA-
J698Z
1
82 DW6394-082 Large Gear 1
83 DW6394-083
Ball Bearing XA-
J6902RS
1
84 DW6394-084 Motor Output Shaft 1
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
85 DW6394-085
Ø28 mm Retaining
Ring
1
86 DW6394-086 Gearbox Cap 1
87 DW6394-087 ST4x35 Screw 6
88 DW6394-088
Right Hand Grip
Housing
1
89 DW6394-089
Lower Right Motor
Housing
1
90 DW6394-090 ST4.2x16 Screw 20
91 DW6394-091 Right Bottom Cover 1
92 DW6394-092
Power Cord Stress
Relief
1
93 DW6394-093 Vacuum Tube 1
94 DW6394-094 Ø35 Adapter 1
95 DW6394-095 Hex Wrench 5 mm 1
96 DW6394-096 Ø57 Adapter 1
