15
No. Part No. Description Qty.
59 DW6395-059
Transmission Shaft
Tube
1
59A DW6395-059A
Right Rear
Connector
1
59B DW6395-059B
Right Front
Connector
1
59C DW6395-059C Ring Shield 2
59D DW6395-059D Ball Bearing 6001 2
59E DW6395-059E Compression Spring 1
59F DW6395-059F Connecting Shaft 1 1
59G DW6395-059G Connecting Shaft 2 1
60 DW6394-060 Hose Adapter 1
61 DW6395-061 Soft Grip 3
62 DW6394-062 Ø10 Retaining Ring 1
63 DW6394-063 Ø14 Retaining Ring 1
64 DW6394-064 M4x20 Screw 1
65 DW6394-065 Carbon Brush Cover 2
66 DW6394-066 Carbon Brush 2
67 DW6394-067 Carbon Brush Holder 2
67A DW6394-067A
Carbon Brush
Winding
2
68 DW6394-068 Motor Housing 1
69 DW6394-069 Bearing Sleeve 1
70 DW6394-070 Ball Bearing 608NSK 1
71 DW6394-071 Stator 1
72 DW6394-072 ST4x55 Screw 2
73 DW6394-073 Motor Cap 1
74 DW6394-074 Rotor 1
75 DW6394-075
Ball Bearing
6000NSK
1
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
76 DW6394-076 Ø25.8x1.8 O-Ring 1
77 DW6394-077 Gearbox Bottom 1
78 DW6394-078
Ball Bearing
CSR608Z
1
79 DW6394-079 Double Gear 1
80 DW6394-080
Roller Bearing
HK0810
1
81 DW6394-081
Ball Bearing
XAJ698Z
1
82 DW6394-082 Large Gear 1
83 DW6394-083
Ball Bearing
XAJ6902RS
1
84 DW6394-084 Motor Output Shaft 1
85 DW6394-085
Ø28mm Retaining
Ring
1
86 DW6394-086 Gearbox Cap 1
87 DW6394-087 ST4x35 Screw 6
88 DW6394-088
Right Hand Grip
Housing
1
89 DW6394-089
Lower Right Motor
Housing
1
90 DW6394-090 ST4.2x16 Screw 20
91 DW6394-091 Right Bottom Cover 1
92 DW6394-092
Power Cord Stress
Relief
1
93 DW6394-093 Vacuum Tube 1
94 DW6394-094 Ø35 Adapter 1
95 DW6394-095 Hex Wrench 5mm 1
96 DW6394-096 Ø57 Adapter 1
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.
