Wen HB6319 User Manual

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 Power Cord 1
2 Cord Sleeve 1
3
Self-tapping Screw,
ST4x16
2
4 Cord Clamp 1
5 Switch 1
7 Support Bracket 1
8
Self-tapping Screw,
ST4x16
9
9 Label 1
101 Housing Assembly 1
13 Spring 1
14 Retaining Ring, 7mm 1
15 Washer, 8mm 1
16 Adjustment Knob 1
17 Label 1
18 Stator 1
19
Self-tapping Screw,
ST4x45
2
20 Rotor Guide 1
21 Damper 1
102 6318-102
Brush Holder Assem-
bly
2
24 6318-022 Brush 2
103 6318-104 Rotor Assembly 1
27 Spring 1
104 6318-027 Front Drum Assembly 1
36 Base Plate 1
37 Spring 1
38 Belt Housing 1
39
Self-tapping Screw,
ST3x16
1
No. Part No. Description Qty.
40
Self-tapping Screw,
ST4x16
3
41 Bearing Cover 1
42 Bearing 608-RS 1
43 Left Housing 1
44
Self-tapping Screw,
ST4x30
4
45
Self-tapping Screw,
ST3x10
2
46 6318-044 Small Gear 1
47 6318-045 Timing Belt 1
48 Belt Cover 1
49
Self-tapping Screw,
ST3x12
2
50 Belt Drive Gear 1
51 Spring Washer 1
52
Self-tapping Screw,
ST4x16
3
53 Bearing 627-2Z 1
54 Axial Gear 1
55 Nut, M8 1
56 6318-055 Belt Drum 1
57 Washer 1
58 Washer 1
59 Retaining Ring 1
60
Self-tapping Screw,
ST4x16
4
105 6318-105 Rear Drum Assembly 1
66 Washer 1
106 6318-106 Gear Assembly 1
70 6318-068 Sanding Belt, 80-grit 1
71 HB6319-071 Dust Bag Assembly 1
NOTE: Not all parts may be available for purchase. Parts and accessories that wear down over the course of
normal use are not covered under the warranty.
16
