Wen MM1011T User Manual

EXPLODED VIEW & PARTS LIST
27
No. Part No. Description Qty.
109 MM1011-109
Toothed Clamping
Ring, 5mm
1
110 MM1011-110 Movable Cover Plate 1
111 MM1011-111 Rivet, Ø3x6 4
112 MM1011-112 Guard Linkage Arm 1 1
113 MM1011-113
Guard Linkage Arm
Washer
1
114 MM1011-114 Guard Linkage Arm 2 1
115 MM1011-115 Rivet 3
116 MM1011-116 Pan-Head Screw 1
117 MM1011-117 Guard Linkage Arm 3 1
118 MM1011-118
Guard Linkage Arm 3
Screw
1
119 MM1011-119 Guard Spring 1
120 MM1011-120
External Circlip,
42mm
1
121 MM1011-121 Arbor Insert 1
122 MM1011-122 Inner Flange 1
123 BL1040 Blade 1
124 MM1011-124 Outer Flange 1
125 MM1011-125 Arbor Washer 1
126 MM1011-126
Arbor Screw, M8x16
(Left-Hand Threaded)
1
127 MM1011-127 Fence Extension 1
128 MM1011-128
Fence Extension
Lock Knob
1
No. Part No. Description Qty.
129 MM1011-129 Screw, M6x18 1
130 MM1011-130 Screw, M8x25 2
131 MM1011-131 Fence 1
132 MM1011-132 Washer, 8mm 1
133 MM1011-133
Extension Blocks,
Left & Right
1
134 MM1011-134 Base 1
135 MM1011-135 Rubber Foot 4
136 MM1011-136 Hold-down Clamp 1
137 MM1011-137 Clamp Arm 1
138 MM1011-138 Clamp Plate 1
139 MM1011-139
Screw, M4x10, and
Washer
3
140 MM1011-140 Guard Spring Screw 1
141 MM1011-141
Self-Tapping Screw,
ST4x6
1
142 MM1011-142 Laser Wire Cover A 1
143 MM1011-143 Laser Wire Cover B 1
144 MM1011-144 Dust Port Adapter 1
146 MM1011-146 Screw, M5x12 4
147 MM1011-147
Extension Block
Support Rod
4
152 MM1011-152 Laser Mount 1
153 MM1011-153 Laser Assembly 1
154 MM1011-154 Screw, M4x20 2
155 MM1011-155 Screw, M4x8 1
