The pressure washer is shipped without oil.
User must add the proper amount of oil before
operating the pressure washer for the first time.
The oil capacity of the engine crankcase is 16.9
fl. oz. For general use (above 40° F), we recom-
mend 30W, 4-stroke engine oil.
ENGINE OIL RECOMMENDATIONS
Select good quality oil bearing the American Petroleum Institute (API) service classifications SJ, SL, or SM. (Syn-
thetic oils may be used.) Use the SAE viscosity grade of oil from the following chart (Fig. 7A) that matches the start-
ing temperature anticipated before the next oil changes.
10
PRESSURE WASHER PREPARATION
ATTACHING THE SPRAY GUN (Fig. 5 & 6)
1. Screw the spray wand and the trigger handle together until they are secure.
2. Insert the inlet coupler of the spray hose into the threaded fitting on the high pressure spray gun and thread the
black nut on by turning clockwise until it is hand tight.
Fig. 6
Fig. 5
To add oil, follow these steps: (Fig. 7B)
1. Make sure the pressure washer is on a level surface. Do not
tilt the pressure washer to fill. Oil to flow into engine areas and
damage the machine. Keep the pressure washer level!
2. Remove the dipstick from the engine. (Fig. 7B)
3. To check the oil level: wipe the dipstick with a clean rag.
Insert the dipstick into the oil fill opening without screwing it in.
Remove the dipstick to check the oil mark.
4. Add oil (not included) slowly until the oil mark reaches to the
top of the dipstick. The capacity of the oil tank is 16.9 fl. oz. Do
not over fill the crankcase.
6. Check for oil leaks and clean any spilled oil. Tighten dipstick
firmly.
ADD ENGINE OIL
Fig. 7B
Fig. 7A
Oil
