Wenger Showmobile Mobile Stage and Canopy User Manual

6
Specications
Dimensions
Closed for Transport:
Length � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 33'-8"
Height � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13'
Width � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8'-5"
With roof/canopy, hydraulic stage, and end panels fully open:
Length � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 33'-8"
Height � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 20'-10"
Width � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16'-5"
Main stage size � � � � � � � � � � � � � � � � � � � � � � � 28' x 6'-6"
Hydraulic stage size � � � � � � � � � � � � � � � � � � � 28' x 8'
Weight
Gross weight (GVW) (approximate)
Basic unit with 1 stairway � � � � � � � � � � � � 13,490 lb
Basic unit with 1 stairway and ADA lift� � � 14,240 lb
Tongue weight (approximate)
Basic unit with 1 stairway � � � � � � � � � � � � 1,600 lb
Basic unit with 1 stairway and ADA lift� � � 2,000 lb
Gross vehicle weight rating � � � � � � � � � � � � � � 16,000 lb
Electrical System
Electrical requirements � � � � � � � � � � � � � � � � � 110-volt 60 Hz, 1-phase, 3-wire, 30-amp circuit via NEMA L5-30
LED work lights � � � � � � � � � � � � � � � � � Four sets of four LED strips located in various locations across the canopy
Outlets (standard) � � � � � � � � � � � � � � � � � � � � � Two duplex outlets on stage; one duplex outlet by charger
Additional outlets (lighting upgrade) � � � � � � � Two quadplex and one duplex outlet in roof/canopy
Battery 12-volt, BCI #8D
Battery charger � � � � � � � � � � � � � � � � � � � � � � � 4-amp fully-automatic charger/maintainer
Note: Before each use, charge battery for 24 hours�
Tires
Size � � � � � � � � � � � � � � � � � � � � � � � � � � � � � LT235/85R16BG G-rated tubeless
Pressure � � � � � � � � � � � � � � � � � � � � � � � � � � � � 110 psi (verify maximum ination pressure marked on tire sidewall)
Leveling System
Standard
Four hand-cranked leveling jacks with 18" travel� Each jack is rated at 12,000 lb
Optional
Hydraulically-operated automatic leveling system, controlled by wireless remote control
Axle, Wheel and Hub Assembly
Two highway-rated torsion-type axles� Each axle has 7,200 lb capacity
Brakes
Dexter two-sided adjustable electric brake, 12-1/4" x 2-1/2", 12-volt
Breakaway Switch
12-volt, connected to on-board battery
Note: Specications are subject to change without notice.
