21
Mount a maximum 300 lb of equipment
on front edge of roof/canopy
!
CAUTION
If hydraulic pump runs, but roof/canopy
does not lift, there is too much weight.
!
CAUTION
Optional Theatrical Lighting Packages
Showmobiles that have optional theatrical lighting packages will include:
Utility Package: (Included with standard Showmobile)
• 16 strips of housed, LED lights
- Total Intensity: 40,000 lumens
- Color temperature: 4000k
Show lighting upgrade, includes Utility Package lighting plus:
• Wall mounted reprogrammable 5 preset DMX controller (pre-programed for basic function from the factory)
• 5 pin DMX override port for optional external control
• 5 upstage RGB batten downlights
• 8 canopy mounted RGBWA-UV front wash xtures
- Total additional intensity: 38,000 lumens
Performance lighting upgrade, includes Utility Package lighting plus:
• Wall mounted reprogrammable 5 preset DMX controller (pre-programed for basic function from the factory)
• 5 pin DMX override port for optional external control
• 5 upstage RGB batten downlights
• 4 high output canopy mounted LED prole xtures
- CRI (Color Rendering Index): 97�2
- Color Temperature: 3200k
- 50-degree lens
- Total additional intensity: 57,000 lumens
The theatrical light xtures and protruding cables
from the canopy are rated IP65 to give them a
better longevity in the eld and protect the
electronics against any unpredicted light weather
that may occur�
Do not operate the Showmobile in bad weather�
Read the manufacturer's manuals and understand
the limits of the xtures. In areas where extreme
climate may exist, it may be necessary to remove
the canopy xtures and store in a climate controlled
area for long storage periods�
The maximum ambient operation temperature is
104° F (40° C) and the minimum ambient
operational temperature is -4° F (-20° C).
Wenger recommends storing the canopy xtures
in a climate controlled area if the Showmobile is
going to be outside in less than -22° F (-30° C)
weather�
