Start
36
TROUBLESHOOTING: Wireless Remote Control (Transmitter & Receiver)
Yes
Yes
Yes Yes
Yes Yes
Yes
1.
Is the
power
LED
(located
near big
orange
capacitor)
on?
2.
Is white
relay clicking
on upon
initialization?
3.
Is RF LED
(light by itself
across from
power LED)
on? (10 sec.
when 1st
turned on in
correlation with
function switch
operation)
4.
Are the
output LED’s
(row of
lights)
operating
according
to their
respective
outputs?
5.
Do the
outputs have
voltage when
operating
their
respective
functions?
6.
Do you
have
acceptable
range?
7.
Are
solenoids
activating
when
operating
respective
function?
If other
problems
persist,
call for a
RGA #.
No
•Check voltage into
receiver from source
•Check 15Amp fuse
No
•LED possibly inoperative
•Function switch inoperative
– check Tx faceplate for
loose wires or bad
connections
No
•Possible failure in:
– pump-up circuit
– driver circuit
– relay not transferring
voltage
•Call for a RGA #
No
•Likely problem on vehicle
– check for loose
connections
– check for bad solenoid
– check for ground at
solenoid
No
•Antenna possibly bad
•Problem in RF section
•Battery low in transmitter
•Receiver antenna positioned
less than 2ft. from vertical
metal or shielded by external
surface
•If problem persists, call for a
RGA #
No
•Possible microprocessor failure
•If flashing or intermittent, check
for:
– constant input voltage
– flashing RF LED
– antenna placement
•If problem persists, call for a
RGA #
Yes
Yes
No
No
2B.
Are
transmitter
and receiver
address codes
matched?
(12-position
DIP switch)
2A.
Is RF LED
on upon
initialization?
No
•Ensure transmitter is transmitting:
– check battery
– check antenna on Rx and Tx
– tune a manually tuned radio to
99.2 FM, depress toggle switch
and listen for distinct-patterned
sound other than static
•Problem likely in RF section
– call for a RGA #
•Match
switches
•Switch all address codes to lows
and re-initialize transmitter (turn
off
and back on)
•Reset address codes to original
settings and test
•If problem persists, call for a
RGA #
