6
EN
OPT2002 OPT2004 OPT2006
Optical Data
Working Range 30…80 mm 40…160 mm 50…350 mm
Measuring Range 50 mm 120 mm 300 mm
Resolution < 8 µm < 20 µm < 50 µm
Resolution (Speed-Mode) < 12 µm < 30 µm < 80 µm
Linearity 0,1 % 0,1 % 0,15 %
Linearity (Speed-Mode) 0,2 % 0,2 % 0,2 %
Light Source Laser (red) Laser (red) Laser (red)
Wave Length 660 nm 660 nm 660 nm
Laser Class 1 1 1
Service Life (25 °C) 100000 h 100000 h 100000 h
max. Ambient Light 10000 Lux 10000 Lux 10000 Lux
Electrical Data
Supply Voltage 18…30 V DC 18…30 V DC 18…30 V DC
Light Spot Size at begin working range 0,5×1 mm 0,5×1,2 mm 0,6×1,5 mm
Light Spot Size at end working range 1×2 mm 1×2,5 mm 1,5×4 mm
Current Consumption (Ub = 24 V) < 80 mA < 80 mA < 80 mA
Measurement Rate 1000/s 1000/s 500/s
Response Time 1000 µs 1000 µs 2000 µs
Response Time (Resolution-Mode) 2000 µs 2000 µs 4000 µs
Temperature Drift < 5 µm/°C < 10 µm/°C < 25 µm/°C
Temperature Range –25…50 °C –25…50 °C –25…50 °C
Analog Output 0…10 V 0…10 V 0…10 V
Current Output Load Resistance < 1 mA < 1 mA < 1 mA
Analog Output 4…20 mA 4…20 mA 4…20 mA
Current Output Load Resistance < 500 Ohm < 500 Ohm < 500 Ohm
Voltagedrop PNP-Error Output < 2,5 V < 2,5 V < 2,5 V
Switching Current PNP-Error Output < 200 mA < 200 mA < 200 mA
Short-Circuit Protection yes yes yes
Reverse Polarity Protection yes yes yes
Mechanical Data
Adjustment Teach-In Teach-In Teach-In
Housing Plastic Plastic Plastic
Protection Mode IP67 IP67 IP67
Connection M12×1, 8-pin M12×1, 8-pin M12×1, 8-pin
Protection Class III III III
Reference material: Kodak white 90 % remission
