The dust skirt (C) serves as a seal for the bottom of the machine to act as a
vacuum chamber helping the dust stay contained under the machine. If the skirt
is too far from the ground, the dust containment is reduced.
To adjust the skirt:
1. Pull one end of the skirt off of the machine until you reach the middle of the
skirt.
2. Position the skirt until it is barely touching the ground and repeat with the other
end.
!
!
!
Avoid positioning the skirt too low as it will drag against the ground, wearing the
skirt out prematurely and possibly preventing smooth machine movement.
!
!
!
To adjust the handle, pull the pin (D). Adjust the handle to a comfortable
operating position. Re-insert the pull pin.
!
!
!
!
Failure to check the pull pin is fully reinserted could result in damage to the
machine or personal injury as the handle could release unexpectedly when the
machine is being operated or tilted back.
!
!
!
!
When the machine is first plugged in, a start-up screen will appear showing the
model of the VFD and the software version that it has been released with.
After the machine runs through its initial start-up sequence, the screen will show
the VFD status and pad driver speed in revolutions per minute (RPM).
Once the machine reaches the desired speed, the speed will remain constant as
long as the load applied remains below 100%. If the machine is running at speed
and the load begins to exceed 100%, the machine will reduce its speed as a
protective measure to try and alleviate the outstanding load. The current running
speed will be displayed. This happens under demanding conditions and is
normal.
