EXPLODED VIEW AND PARTS LIST – RAPTOR XTI
!
011-0127-01 RAPTOR XTi PARTS LIST
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
100-0829-01
Drive Train, Lower Shell
2
24
590-0197-00
Fastener
3
16
500-0222-00
Bearing
4
8
500-0269-00
Sprocket
5
2
500-0260-00
Idler Sprocket
6
4
500-0228-00
Bearing
7
2
580-0071-00
Pin
8
2
500-0261-00
Bearing
9
1
500-0258-01
Sprocket
10
1
520-0044-00
Belt
11
6
590-0193-00
Fastener
12
1
100-0509-00
Vacuum Tube, Drive Train
13
1
580-0195-00
Gasket
14
4
540-0179-00
Threaded Bumper
15
2
590-0154-00
Fastener
16
8
580-0244-00
Radial Shaft Seal
17
8
100-0830-00
Water Seal
18
1
100-0841-01
Drive Train, Upper Shell
19
9
590-0317-00
Fastener
20
1
580-0255-01
Gasket, Drive Train
21
4
590-0008-00
Fastener
22
1
530-0024-00
Motor
23
1
540-0178-00
Grommet
24
1
120-0067-00
Motor Mounting Plate Assembly
25
2
540-0156-00
Strain Relief
26
8
590-0133-00
Fastener
27
1
120-0069-00
Shroud Assembly, Motor
28
4
590-0125-00
Fastener
29
9
590-0171-00
Fastener
30
2
590-0276-00
Fastener
31
2
590-0188-00
Fastener
32
4
590-0194-00
Fastener
33
1
590-0196-00
Fastener
34
1
590-0148-00
Fastener
35
2
580-0131-00
Wheel
36
2
580-0132-00
Bushing
37
1
130-0152-00
RPA Assembly, Lower
38
1
100-0544-01
Access Plate, Handle Junction Box
39
1
130-0153-01
RPA Assembly, Upper
40
1
590-0113-00
Fastener
41
1
580-0112-00
Extension Spring
42
2
590-0256-00
Fastener
43
1
590-0212-00
Fastener
44
1
540-0234-00
Micro Switch
45
1
100-0545-02
DM Mount, Handle Junction Box
46
1
130-0067-01
DM Lever Assembly
47
1
100-0700-01
Spanner Shaft
48
1
590-0300-00
Screw
