11
9. Make sure that all parts are properly tightened before you use the treadmill. To protect the floor or car-
pet, place a mat under the treadmill. To avoid damage to the console, keep the treadmill out of direct sunlight.
Keep the included hex keys in a secure place. One of the hex keys is used to adjust the walking belt (see
pages 20 and 21). Note: Extra parts may be included.
8. Attach the Storage Latch (42) to the Left Upright
(73) with two #10 x 1" Tek Screws (7); start
both Tek Screws, and then tighten them.
7. Start an M8 x 15mm Screw (2) with an M8 Star
Washer (36) into each Upright (73, 74).
Firmly tighten all six M8 x 15mm Screws (2).
8
7
7
36
36
73
73
74
2
42
2
2
2
