Lit. No. 49513, Rev. 00 32 August 15, 2011
MOUNTING SNOWPLOW TO VEHICLE
1. After seating snowplow horns in receiver
brackets, pull handle up; shoe will lift off the
ground.
2. Pull and hold lock pin out; then rotate handle
UP and release lock pin. It must lock into
UPPER hole. Stand hook must grip receiver
pin.
3. Repeat Steps 1 and 2 on other side of
snowplow. (Not required for HTS™ blades.)
4. Connect electrical plugs.
ON
Shoe
Handle
ON
Receiver Pin
Stand Hook
Handle
(Pull)
Lock Pin
To Next Page
