Western HTS - Air Removal - WIDE-OUT Blades

Lit. No. 49513, Rev. 00 97 August 15, 2011
MAINTENANCE
Air Removal – WIDE-OUT™ Blades
11. Turn the control ON and completely extend
and retract the driver-side wing several times.
Repeat for the passenger-side wing. With
the wing and lift rams fully retracted, turn the
control OFF.
12. Fill the reservoir to the top of the fi ll hole and
replace the fi ll plug.
NOTE: Loosen fi ll plug slowly to relieve any
pressure in the reservoir.
13. Turn the control ON. Angle blade fully left
and right and raise and lower the snowplow
several times. Activate the control FLOAT
function and manually collapse the lift ram all
the way after each lowering of the blade. With
all rams fully retracted, turn the control OFF.
14. Fill the reservoir to the top of the fi ll hole and
replace the fi ll plug.
WARNING
To prevent accidental movement of
the blade, always turn the control OFF
whenever the snowplow is not in use. The
power indicator light will turn OFF.
