Western HTS - System Capacity; Pump Motor Specifi Cations (All Blades)

Lit. No. 49513, Rev. 00 26 August 15, 2011
GETTING TO KNOW YOUR SNOWPLOW
MVP PLUS™ Blades
12-volt DC with +/– Connection
2200–2300 psi Pump Relief Valve
4550–4650 psi Plowing Relief Valve
3650–3750 psi Back Dragging Relief Valve
4.5" dia 1.5 kW Motor
0.000652 gal/rev Pump
Hydraulic Hose 1/4 SAE 100R1 and 3/8 SAE 100R17
WIDE-OUT™ Blades
12-volt DC with +/– Connection
2200–2300 psi Pump Relief Valve
4000 psi Plowing Relief Valve
1500 & 1700 psi Wing Plowing Relief Valves
4.5" dia 1.5 kW Motor
0.000652 gal/rev Pump
Hydraulic Hose 1/4 SAE 100R1 and 3/8 SAE 100R17
System Capacity
• FloStat
®
Unit Reservoir ..............1-3/4 quarts
• FloStat System Total .....2-3/8 to 2-3/4 quarts
Pump Motor Specifi cations
HTS™ Blades
12-volt DC with +/– Connection
1600–1700 psi Pump Relief Valve
4000 psi Angling Relief Valve
3" dia 0.8 kW Motor
0.000477 gal/rev Pump
Hydraulic Hose SAE 100R1
Straight Blades
12-volt DC with +/– Connection
1700–1800 psi Pump Relief Valve
4000 psi Angling Relief Valve
4.5" dia 1.5 kW Motor
0.000477 gal/rev Pump
Hydraulic Hose 1/4 SAE 100R1 and 3/8 SAE 100R17
