Lit. No. 49513, Rev. 00 86 August 15, 2011
MAINTENANCE
4. Replace the cutting edge when it is worn to
the bottom of the blade.
MVP PLUS™ Cutting Edge: To equalize
wear, refer to the leveling adjustment
procedure in the following cutting edge
section.
5. Straight Blade and WIDE-OUT™ Trip
Spring Adjustment: To adjust trip spring
tension, adjust the eyebolts located at the top
of the blade. Loosen the locknut (nut closest to
the spring), and tighten the adjusting nut (nut
farthest from the spring) until the coils begin to
separate. When tension is properly adjusted,
a sheet of paper should pass between the
second and third coils. When the proper
tension is reached, tighten locknut.
6. Blade Finish: If the powder-coated fi nish is
nicked or scratched, repair the surface and
paint with WESTERN
®
red or black paint in
aerosol or quart can.
