Lit. No. 13648/9511 3 January 1, 2002
SAFETY INFORMATION
NOTE: Maintain proper belt tension for correct
belt functioning.
NOTE: Lubricate grease fittings after each use.
Use good quality multi-purpose grease.
When tightening fasteners, refer to Torque Chart for
the recommended fastener values.
Torque Chart
CAUTION
DO NOT leave unused material in hopper.
Material can freeze or solidify, causing unit to
not work properly. Empty and clean after each
use.
Recommended Fastener Torque
Chart (Ft.-Lb.)
Size
SAE
Grade 2
SAE
Grade 5
SAE
Grade 8
1/4-20
5/16-18
3/8-16
3/8-24
7/16-14
1/2-13
9/16-12
5/8-11
3/4-10
7/8-9
1-8
6
11
19
24
30
45
66
93
150
202
300
9
18
31
46
50
75
110
150
250
378
583
13
28
46
68
75
115
165
225
370
591
893
Metric Grade 8.8 (Ft.-Lb.)
Size TorqueSize
Torque
M 6
M 8
M 10
M 12
M 14
M 16
7
17
35
60
95
155
These torque values apply to mount assembly fasteners
except those noted in the instruction.
NOTE: Airborne noise emission during use is
below 70 dB(A) for the spreader operator.
CAUTION
Disconnect electric power at spreader electrical
wiring harness connection and tag out if
required before servicing or performing
maintenance.
