3. Mounting the MORS Kit (Optional)
The MORS kit should be mounted in an easily accessible location. The supplied wire
harness should be routed from the MORS interface of smart power unit to the MORS
kit.
wall mounting hole dimension
4. Mounting the External Microphone Module (Optional)
The external microphone module shall be mounted on a solid surface (wall or ceiling),
away from loud noise sources, away from the main control panel but closest to the
main living area. The supplied wire harness should be routed from the control panel
to the external microphone module.
wall moun tin g hole dim ension
